Semi-auto Double Face Bottle Labeling Machine

Semi-auto Double Face Bottle Labeling Machine thumbnail-1
Semi-auto Double Face Bottle Labeling Machine photo-1
US$ 3,500 - 4,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Application:
Beverage, Chemical, Commodity, Food, Medical
Packaging Type:
Bottles
Contact Supplier Request Quote Chat Now
Shanghai Shenhu Packaging Machinery Equipment Co., Ltd.
Gold Verified Supplier
5Yrs
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai Port Bottle Labeling machine
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Application Beverage, Chemical, Commodity, Food, Medical
Packaging Type Bottles
Packaging Material Glass, Metal, Plastic
Automatic Grade Semi-Automatic
Driven Type Hydraulic
Voltage 220V/50HZ, 220V, 50Hz
Power 1.1 Kw
Place of Origin Shanghai, China
Brand Name Bottle Labeling machine
Model Number Bottle Labeling machine
Dimension(L*W*H) 850mm X 410mm X 720mm
Weight 50 Kg
After-sales Service Provided No overseas service provided

Specifications

Bottle Labeling machine
1. Speed: 30 pics/min,
2. Double Face
3. Stickers Label

Product Name: Bottle Labeling machine

Description:

             Parameter Name

          Specific Parameter Values

Labeling Accuracy

± 0.5mm (except for products & labels' error)

Labeling Speed

15 to 25 pcs / min (related to products' size)

Applicable Products' Size

Length: 20mm ~ 200mm; Width: 20mm ~ 150mm;Thick:0.2mm~120mm

Applicable Label's Size

Length: 15mm ~ 200mm; Width: 20mm ~ 200mm;

Machine's Size

Approximately 850mm × 410mm × 720mm
(length × width × height);

Power supply

220V/50HZ

Total Weight

Approximately 41Kg

Applicable label’s inner diameter

Ø76mm

Applicable label’s outer diameter

Ø 240mm

Voltage

220V

Air Pressure

0.4-0.6Mpa





Semi-auto Double Face Bottle Labeling machine



NO.

Mechanism’s Name

Mechanism's Description

1

The Brake of Feed Tray

The prevention of over labeling

2

Feed Tray

Ready to put on label volumes

3

Rack



4

Shrapnel to Press the Label

Press the label to ensure the label’s tension

5

Roller

For label's detour

6

Label Detecting Electric-eye

Detect the label

7

The Material Receiving Machine

Recycle the label’s backing sheet

8

‘T’Shape Handle

Fasten the drawing mechanism

9

Drawing Mechanism

By pulling the backing sheet, peel off the label, the degree of tightness can be adjusted

10

Electric Controlling Box

Used for the electric circuit configuration of the machine

11

Tool Table

Used to put on workpiece

12

Air Blowing Pipe

Hold up the label and transit it to the sucker successfully in the process of label peeling

13

Air Cylinder

Used to finish the action of labeling

14

Fine Adjustment Screw

Small adjustment for sucker and the height of workpiece

15

Film to Press the Label

Guarantee the tension of the label

16

Drawing Motor

Provide power to the label belt



Rear View:



Semi-auto Double Face Bottle Labeling machine



1.Air Blowing Pipe 2.Pedal Interface 3.Standby Port 4. Standby Port 5.Air Pipe Interface 6.Barometer 7.Air Pressure Governor



Scope



  1. Applicable Label: adhesive label, adhesive film, electronic supervision code, bar code, etc.

 2. Applicable Products: The products required to be labeled on the plane, cambered surface , circumferential surface, concave surface, convex

surface or other surfaces.


 3. Industry: Widely used in cosmetics, food, toys, daily chemical, electronics, pharmaceutical and other industries;



 4. Application: The labeling of shampoo flat bottles , packing box’s labeling, bottle caps, plastic shell, etc.





Technical Parameters



             Parameter Name

          Specific Parameter Values

Labeling Accuracy

± 0.5mm (except for products & labels' error)

Labeling Speed

15 to 25 pcs / min (related to products' size)

Applicable Products' Size

Length: 20mm ~ 200mm; Width: 20mm ~ 150mm;Thick:0.2mm~120mm

Applicable Label's Size

Length: 15mm ~ 200mm; Width: 20mm ~ 200mm;

Machine's Size

Approximately 850mm × 410mm × 720mm
(length × width × height);

Power supply

220V/50HZ

Total Weight

Approximately 41Kg

Applicable label’s inner diameter

Ø76mm

Applicable label’s outer diameter

Ø 240mm

Voltage

220V

Air Pressure

0.4-0.6Mpa



Samples:



Semi-auto Double Face Bottle Labeling machine



Semi-auto Double Face Bottle Labeling machine
