Rescue Tools Inflatable Cushions

Rescue Tools Inflatable Cushions thumbnail-1
Rescue Tools Inflatable Cushions thumbnail-2
Rescue Tools Inflatable Cushions thumbnail-3
Rescue Tools Inflatable Cushions photo-1
Rescue Tools Inflatable Cushions photo-2
Rescue Tools Inflatable Cushions photo-3
US$ 1 - 2 MOQ: 1 Set
Key Specifications
Get Latest Price
Place of Origin:
Shandong, China
Brand Name:
Starye
Model Number:
B20
Contact Supplier Request Quote Chat Now
Shandong Starye Firefighting Equipment Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao/Shanghai/Guangzhou
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Shandong, China
Brand Name Starye
Model Number B20
Rescue Tools Inflatable Cushions

Product Information



Description

1. The inflatable cushions are made up of aromatic polyamide fiber reinforcement, 4 layers in total. Primarily used in low insertion situations with heavy weights to be lifted such as, building lifting, emergency rescue, vehicle extrication, heavy recovery and truck moving and so on.

2. Thickness of the inflatable cushions are only 25mm which can lift tons of objectives easily.

3. This inflatable cushions can be powered by high pressure gas cylinder, foot air pump or pump station.

4. Anti-skipping design on the surface and thicken edge ensures the safety for operation.



Application

This inflatable cushions can be used for vehicle extrication, building collapse, disaster rescue, aircraft accident etc. namely rescue situations.



Features

1. Noiseless, shamble, lift the heaviest object stably;

2. Long using life, the special anti-skip design on surface can maintain the skid resistance when work on grass/ sediment etc;

3. Wear-Resisting & Anti-crack;

4. Corrosion resisting, Flexible.



Specifications

Model

B1

B 5

B8

B10

B15

B18

B22

Area (cm)

15*15

25*25

32*32

37*37

45*45

50*50

55*55

Thickness(mm)

26

26

26

26

26

26

26

Lifting Force (t)

1

5

8

10

15

18

22

Max Lift Height (mm)

70

110

130

160

200

220

250

Air Volume Needed (L)

0.6

2.1

5.2

8.6

16.9

22

32.9

Air Feeding Period(s)

<30

<30

<30

<30

<30

<30

<30

Max.Pressure(bar)

8

8

8

8

8

8

8

Test pressure (bar)

12

12

12

12

12

12

12

Low Temperature(℃)

-40

-40

-40

-40

-40

-40

-40

High Temperature(℃)

+70

+70

+70

+70

+70

+70

+70

Weight(kg)

0.6

1.5

2.5

4.0

5.3

6.5

8.1



Model

B28

B 32

B 40

B 45

B 54

B 68

Area (cm)

60*60

65*65

75*75

85*85

90*90

95*95

Thickness(mm)

26

26

26

26

26

26

Lifting  Force (t)

28

32

40

45

54

68

Max Lift Height (mm)

280

360

420

450

500

550

Air Volume Needed (L)

43.8

56.7

86.5

126.2

148.9

182.8

Air Feeding Period(s)

<30

<30

<30

<30

<30

<30

Max. Pressure (bar)

8

8

8

8

8

8

Test Pressure (bar)

12

12

12

12

12

12

Low Temperature(℃)

-40

-40

-40

-40

-40

-40

High Temperature(℃)

+70

+70

+70

+70

+70

+70

Weight (kg)

11.2

13.3

18.2

22.5

25.3

28.6





More Pictures





Rescue Tools Inflatable Cushions



Rescue Tools Inflatable Cushions



Rescue Tools Inflatable Cushions





Packing & Shipment



Shipment

Alternative Methods: DHL, UPS, Fedex, TNT ; Air Freight; Sea Freight;





Payment Methods




1. T/T Prepaid;
2. Western Union;
3. Paypal;
4. L/C;
5. Cash.




Our Services





1. How long is your warranty period?

Total free warranty service of Starye products is one-year(Artificial damage and incorrect use is not included).



2. Quality control
a. Starye company is under control of ISO 9001 system.

b. All equipments are produced according European EN and USA NFPA standard verified by Germany TUV test group.
c. Tests involve in every production process preventing quality problem as much as possible. At least 3 times' tests are applied into each set of final completed equipment before out of workshop.
d. Defective rate of products is less than 1%.



3. If there are some problems with the equipment, can you guarantee that you will bear the cost of all return?
During warranty period, we are committed to bear all the costs for a quality problem. The fastest method is garanteed to solve the problem.





Starye Worldwide Market





We have agents in Russia, Argentina, India, Italy etc. Various types of firefighting & rescue equipments are supplied directly to more than 20 countries each year. Such as Germany, England, Mexico, South Africa, Isreal, Iran, Thailand......







Company Information





Shandong Starye Firefighting Equipment Co., Ltd, one of the most professional manufacturing company located in China, devotes ourselves into researching, manufacturing and selling various firefighting & rescue equipments and tools.



Up to now, Starye products, such as hydraulic rescue equipment, fire suppression equipment, personal protective devices, rescue tripod, inflatable cushions, Fine Water Mist Extinguishing Equipment etc. which are sold and maintained by our official partners in more than 30 countries, are playing a vital role in the wordwide firefighting and rescue job, such as firefighting rescue, forest firefighting, earthquake, traffic extrication and other disasters' rescue, car accident, personal protection and so on.



Quality and service are the two most important terms for us. For all products before shipment, inspection and test on each step and outcome products are strictly required and controlled in our factory. Total free warranty service is carried out on quality problem valid for all clients. Starye will keep innovating high technology on new products all the time to help for rescue as much as we can.
