Specifications
Poly(adipate)ester based TPU ResinsSOTHANE 1000/1100 Series
Suggested Applications:
Seals, Gaskets, Sheets, Film, Tube,Cabl
Poly(adipate)ester based TPU Resins
Characteristics:
ISOTHANE 1000 /1100 series products are polyester poly(adipate)ester based thermoplastic polyurethanes. They exhibit excellent toughness, abrasive resistance, and solvent resistance. These products can be injection molded, blow molded, and extruded.
Properties:
Items |
Units |
ASTM |
1075A |
1080A |
1085A |
1090A |
Specific Gravity |
gr./cm3 |
D-792 |
1.18 |
1.18 |
1.18 |
1.20 |
Hardness |
Shore A D |
D-2240
|
77A
|
82A
|
85A
|
92A
|
Tensile Strength |
Mpa psi |
D-412 |
33 4800 |
34 5000 |
38 5500 |
39 5700 |
Tensile Modulus |
|
D-412 |
|
|
|
|
|
@ 50% elongation
|
Mpa Psi |
3.1 450 |
3.7 540 |
4.1 600 |
7.6 1100 |
|
|
@ 100% elongation
|
Mpa Psi |
4.8 700 |
5.2 750 |
5.9 850 |
9.7 1400 |
|
|
@ 300% elongation
|
Mpa Psi |
10 1500 |
11 1600 |
12 1800 |
23 3300 |
|
Elongation @ Break |
% |
D-412 |
650 |
580 |
580 |
500 |
|
Compression Set 22 hrs @ 23°C 22 hrs @ 70°C |
% % |
D-395 (B) |
25 30 |
25 75 |
30 75 |
25 30 |
Tear Strength |
N/mm lb/in |
D-624 DIE C |
80 460 |
80 460 |
80 460 |
95 550 |
Abrasion Resistance |
mg (loss) |
D-1044 (Taber) H-22 |
15 |
10 |
15 |
10 |
