PRESS MACHINE FOR FPR+PU SANDWICH PANEL

Name: PRESS MACHINE FOR FPR+PU SANDWICH PANEL
Brand: GUOSEN
SKU: 100144537
Availability: InStock

US$ 170,000 - 180,000 MOQ: 1 Set

Key Specifications

Condition:

New

Type:

Hot Press Machine

Place of Origin:

Shandong, China

Qingdao Guosen Machinery Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

QINGDAO PORT

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Type Hot Press Machine

Place of Origin Shandong, China

Brand Name GUOSEN

Model Number BY320x1050/63(1+1)

Voltage 380/220V

Power(W) 20.5kw

Dimension(L*W*H) 25,000*3,400*2,500mm

Weight 95 ton

Certification ISO9001:2000

Warranty 12 months

After-sales Service Provided Engineers available to service machinery overseas

Product Description

(1),dimension of working table (including moving working table and upper fixed working table)	3,200*10,500mm
(2),flatness of working table (including the surfaces that touch the products of upper fixed working table and moving working table )	≤0.5mm/m2
(3),flatness of All surface of working table
the surfaces that touch the products of upper fixed working table and moving working table	≤2mm
The distance between the surfaces that touch the products of upper fixed working table and moving working table	∠1.5mm
The roughness of the surfaces that touch the products of upper fixed working table and moving working table	Ra∠6.3um
(4),Height of moving working table	700mm
(5),Layers	One,and one direction
(6),daylight(stop at any position)	450mm
(7),time for opening or closing	≤60S
(8),pressure of hydraulic system	15MPa
(9),total pressure	630tons, 24pieces oil cylinders with Φ140.
(10),Motor power of hydraulic system	20.5KW
(11),pressure of heating water	0.2MPa
(12),production technology temperature	A. room temp.~40±5℃ B. room temp.~70±5℃
(13),heating power	120KW
