Help CenterZ1162 Control Valve, Hydraulic Control Valve With Electric,20mpa Electric-hydraulic Control Valve for Sanitation Machines
Related Products
-
DYXZT-L12 Series New Developed Electric Valve , Hydraulic Oil Control ValveUS$ 10 - 1,000MOQ: 100 Pieces -
A1034 Hydraulic Electric Blow off Valve ZT-L12 Series Hydraulic Control Valve Factory Directional Valves ManufacturersUS$ 200 - 600MOQ: 1 Piece
-
A1033 Hydraulic Electric Expansion Valve ZT-L12 Series Hydraulic Control Valve Factory Directional Valves ManufacturersUS$ 200 - 600MOQ: 1 Piece
-
SJ-TECHNILOGY Spool Detent Action Oil Valves ,electric Hydraulic Valve,electric Remote Control ValveUS$ 350 - 430MOQ: 10 Pieces
-
XZT-L12F-4OD1U-G1/2(H1476) Electric Remote Control , Electrichydraulic Control and Manual Control Valve SupplierUS$ 350 - 430MOQ: 10 Pieces
Z1163 control valve, hydraulic control valve with electric,20mpa electric-hydraulic control valve for sanitation machines DYXZTL12 electrichydraulic control valve series multiple valve is developed on the basis of the
SQXZTL12 electric and pneumatic control series . It mainly uses electric control when it without
pneumatic and retain the original manual control.It will be diverted from the main circuit of a set of
control circuit,through the solenoid valve to control the multiple valve change it direction. And can
meet customer’s requirements to install a wireless remote control, which can be better achieve
remote control .The monoblock valve has the advantages of compact structure, high working
pressure, good performance, reliable work,and can realize the near and remote control of multiple
actuators. According to customer’s demands,the manual mechanism of directional valve can be
assemble with normally manual ones.This valve is widely used in engineering machinery, sanitation
machinery, mining machinery and other mechanical hydraulic system.
|
Nominal Pressure (Mpa) |
Max. Pressure (Mpa) |
Nom.flow (L/min) |
Max.flow
|
Middle Back. Pressure (Mpa) |
Hydraulic Oil |
||
|
Tem.range (℃) |
Visc.range (mm2/s) |
Filtrating Accuracy (μ m) |
|||||
|
20 |
31 |
40 |
50 |
1 |
-20~+80 |
10~400 |
10 |
Built-in single way valve:valve body with single way valve to prevent back flow of oil
Built-in safty valve:valve body with over load valve,may adjust the system pressure.
Circuit form:Parallel circuit
Control types:electric control to change directions,manual control to change directions
Valve body structure: monoblock structure, 1-8 spools arbitrary combination
Spool function:O,A,Y etc.
Huaian Shengjie Hydraulic Machinery Co., Ltd., established in 1990, is a professional spool directional
control valve manufacturer in China. We specialized in producing directional flow control valve, directional
control hydraulic valve, multiple control spool valve, high pressure multiport valve and etc. Our products are
with outstanding performance, convenient operation, and our products are widely applied to agriculture,
construction, petroleum, fishery, mining and other industries. In additional, we can also offer high quality
hydraulic gear pums.
Main Markets |
South Asia |
Total Annual Sales Volume: |
US$2.5 Million - US$5 Million |
Export Percentage |
41% - 50% |
Factory Information
Factory Size |
30,000-50,000 square meters |
Factory Location |
North of Railway, West of Shenyang Road, Huaiyin Industrial Park |
Number of Production Lines: |
10 |
Number of R&D Staff: |
31 - 40 People |
Number of QC Staff |
Above 50 People |
Management Certification |
ISO14001 ISO9001 |
Contract Manufacturing |
OEM Service Offered Design Service Offered Buyer Label Offered |
Q1: Are you a factory or trading company?
A1: We are a factory.
Q2: Where is your factory located? How can I visit there?
A2: Our factory is located in HUAI AN city, Jiang Su Province, China, near Shang hai or Nan Jing.
You can fly to HUAI AN airport directly.
Q3: What’s the delivery time of your products?
A3: Usually, the delivery time is between 15days to 30days depending on your purchasing quantity.
Q4: How can I get samples?
A4: We are honored to offer you samples.
Q5: How does your factory do regarding quality control.
A5: "Quality is priority. Sheng Jie Hydraulic always attach great importance to quality controlling from
the very beginning to the very end. Our factory has gained ISO9001, ISO40000 certification.
