FRP SMC water tank

Standard packing for export or as customized

Specifications

1.high strength and light weight
2.anti-corrsion and no-leakage
3.long-life service
4.nice appearance
5.easy maintain



Product information

FRP SMC water tank

 Mixture of Unsaturated Polyester Resin, glass-fiber, filler, mold release agent, catalyzer, etc.--by hydraulic press machine under high temperature and press and assembled with bolts and reinforcement materials at the job site.

Advantage of water tank

1. light weight and high strength, which easy to transport and assemble at site

2. excellent waterproof property, with no leakage

3. anti-aging with long service for over 30 years.

4. maintenance-free

5. 1.Clean and pollution-free

6 cost saving

 Detailed specification



Item name	FRP water tank
Techniques	SMC: Sheet Molding Compound
Reinforcing material	Fiberglass, glass fiber and glass mat
Basic Material	Special unsaturated polyester resin
Auxiliary Material	Gel coat resin, firming agent Accelerating agent and abrasive material.
Parameters	Tensile strength (Mpa): ≥60 Bending strength (Mpa): ≥100 Barcol hardness (Mpa): ≥60 Flexural modulus (Mpa): ≥5900 Water absorption: ≤1.0% Fiberglass content: ≥25% Maximum distortion of side wall ≤0.5% Distortion of the bottom≤8mm
Specification	Water tank size:1.0*1.0*1.0m, 1.0*2.0*1.0m, 1.0*3.0*1.5m, etc SMC board size:1.0*1.0m, 1.0*0.5m, 0.5m*0.5m Wall board thickness:5mm,8mm,10mm,12mm,14mm,16mm etc
Measure	0.125-1500m3
Characteristic	1, leak-proof Due to the material is fiberglass reinforce plastic with high density, adding the sealing tape is high  performance with non toxic, so it's leak-proof tank. 2,Long lifetime  Our FRP water tank with maximum distortion of the sidewall is less than 1 percent of the height, maximum  distortion of the bottom center is less than 10mm. The normal durable lifetime is more or less 30 years.
Application	Our FRP water tank is widely used in factory, Enterprises, government hotel, motel, restaurant, residence as storage  facility as well as places with high requirements for water quality, such as hospitals and  food processing plants.  Also use it as equipment in drinking water treatment and fire water supply.

 Different size of water tank

 Structure of water tank



Inner structure



Component

Water tank panel

Accessories



Installation process

we give you instruction manual , easy to operate .Of course , we can send engineers overseas to help you .









Final product



Packing and shipment

Usually we use plywood package or naked package. Some of the products like fan coil unit or table tennis board have

standard carton package. The shipping terms are LCL, 20’ container, 40’ container. Of course , we can design as your requirements







1. Please do not store water higher than 70°C or other liquid (chemicals, oil and so on).

2. Keep away from fire.

3. Prevent pollutants and plunges from outside.

4. Use soft apparatus to clean. As to the new water tank, clean twice before use.

Introduction of  our company

Shengze is a leadind and professional manufacturer of fiberglass product for over 20 years .



Our company specializes in producting fiberglass composite product by pultrusion ,SMC,SMC molding , hand lay out and RTM technology . Our annual capcity can reach to 8000 tons .



With decades of experience and performance based on excellent technology and dedication to the top quality standards in manufacturing and customer satisfaction . Shengze ensures our solutions are the most innovative ones .

Our working environment

Certification



 we sincerely welcome clients from home and abroad to visit and cooperate with us !
