Mini Tractor
Negotiable
/ Set
1 Set(Min.Order)
- 3000 Set / Sets per Month
- T/T
You May Like
-
2015 supply 22hp (16.15kw) farm tractor, XT220 wheel tractor, xingtai 22hp mini farm tractor
-
Small tractor, farming tractor,mini tractor, mini farm tractor, 30hp 4wd farm tractor
-
2015 factory supply cheap small tractor, farming tractor, 30hp 4wd farm tractor
-
2015 factory supply cheap small tractor, farming tractor, 30hp 4wd farm tractor
-
Tractors gold supplier china mini tractor,garden tractor foe sale /20hp mini tractor
-
2015 factory supply cheap 12hp/16hp/18hp/20hp /25hp /30hp small tractor
Product Details
| Condition | New | Type | Wheel Tractor | |
| By wheel | 2WD | Usage | Garden Tractor | |
| Certificate | Other, ISO | Brand Name | XT | |
| Model Number | XT120 | Place of Origin | China |
Product Description
Specifications
Mini Tractor1) 2WD,12HP,direct transimssion
2) We can manufacture other type
Mini Tractor
| Model | XT120 | |
| Type | 4×2 Wheeled Tractor | |
| Rated Tractive Force (kN) | 3.1 | |
| Overall Dimensions(L*W*H, mm) | 2170*1200*1235 | |
| Structural Mass (kg) | 645 | |
| Min. Operating Mass (kg) | 755 | |
| Wheelbase (mm) | 1300 | |
| Wheel Tread (Front/Rear, mm) | 850/880, 960/990 | |
| Min. Ground Clearance (mm) | 275 | |
| Min. Turning Radius (m) | 3.5 | |
| Calculating Speed (km/h) | forward | 2.00/3.82/6.26/7.59/14.48/25.51 |
| reverse | 2.00/7.59 | |
| Hitch Linkage | O Type, Rear-Mounted, Three-Point Linkage | |
| PTO Shaft Type | Rear-Mounted, Dependent, 540 rpm, Clockwise, Φ 35mm | |
| Engine | ||
| Model | DL190-12 | |
| Type | Single Cylinder, Vertical, Water-cooled, 4-stroke | |
| 12-hour Rated Power (kW) | 8.1 | |
| Rotate Speed (r/min) | 2200 | |
| Starting Method | Cranking or Electric | |
| Bore×Stroke (mm) | 90×110 | |
| Fuel Oil Consumption (g/kw*h) | ≤257 | |
| Lubricating Oil Consumption (g/kw*h) | ≤2.04. | |
