4x4 Specification of Dongfeng EQ6689PT COUNTRY-CROSS BUS
Overall Dimensions |
6700* 2240 * 2670 |
Length(mm) |
6700 |
Width(mm) |
2240 |
Height(mm) |
2670,2950 With Outer Luggage rack |
Interior height(mm) |
1680 |
Wheelbase(mm) |
3650 |
Tread Front/Rear(mm) |
1774/1774 |
Front/Rear Overhang(mm) |
1290/1760 |
Min. Ground clearance |
286 |
Approach/Departure Angle(o) |
35/23 |
Brake distance (v fully loaded) |
≤10 |
Fuel consumption (L/100km) |
12 |
Max. Total Mass |
6500 |
Front/Rear Axle (kg) |
3000/3500 |
Max. Speed (km/h) |
80 |
Max. Grade ability (%) |
55 |
Min. turning circle diameter (m) |
16 |
Fuel Tank Capacity (L) |
60/135(main tank) |
Engine |
|
Arrangement of Engine |
Four cylinder in line |
Model |
EQB140-30 140hs Dongfeng Cummins diesel engine |
|
|
Position |
Front |
Displacement (L) |
3.92 |
Bore X stroke (mm) |
/102×120 |
Compression Ratio |
17.3:1 |
Max. Output (kw/rpm) |
92/2800 |
Max. Torque (N.m/rpm) |
410/1400-1600 |
Type of Fuel |
Diesel |
Chassis |
|
Model |
EQ6689KS |
VIN |
LGKY9CCG |
Clutch |
Single,dry,diaphragm spring clutch 330 |
Gearbox |
Dongfeng brand |
Technology and model |
Mechenical Manual,Five forward Gear with one Backward Gear;Model: 17S26B-0030 |
nr. of speeds |
1:6.30,2:3.71,3:2.11,4:1.32,5:1,R:6.6 |
Rear axle |
Single Class Speed Reduction;Welding Chaissis Casing;EQ153;Load Mass:11 Tons |
Front axle |
I-shape beam Frame |
Frame |
Dongfeng frame:28 6-00010/41T |
Suspension system |
Strengthen spring 9/11 |
Steering system |
Chinese power steering gear |
Braking system |
Front&Rear drum,dual-circult service brakding system |
Tyre |
11R18 |
Electric system |
24V minus earth |
Starter |
24V 4.5KW |
Battery/Alternator |
12V-2/28V 70A |
Body |
|
Body structure |
Standard of dongfeng |
Type of floor |
PVC plat-floor PVC floor |
Inner decorating |
Standard |
Door and door pump |
general door ,Pump type:FR803 |
Windows |
Standard |
Emergence exit |
3 |
Nr.Seats (standard/optional) |
19 |
Air-conditioning system |
Optional(Dongfeng Paninco brand) |
Heating system |
Heater by hot water |
Audio and Visual system |
Optional |
Services facilities |
Not |
Others |
Optional |
Electronic station displayPortuguese |
Standard |
Counting passenNger system(entry /exit |
Not |
Engine intercooling system |
Turbocharged and Aftercooled |
Running recorder |
Made in China |
Coin box with protection |
Not |
Metal plaint |
Standard |
Soft dashboard : |
Standard |
Luggage compartment |
Standard |
Fire extinguisher |
Standard |
VDO sensor VDO |
Standard |
AC system AC |
option |
