Help CenterBackhoe Loader
Related Products
Specifications
backhole loaderwith CE
Model:WZY30-25.
Engine: R4105 55kw
Capacity:0.96cm3
Backhole loader
Model:WZY30-25
Total operating weight |
7600Kg |
|
length*width*height |
5900x2200x3750 |
|
wheel base |
2.25m |
|
cab root height |
2.79m |
|
minimum ground clearance |
0.31m |
|
loading bucket capacity |
0.96m3 |
|
digging up capacity |
50.21KN |
|
loading lift capacity |
36.43KN |
|
bucket discharge height |
2.7m |
|
bucket discharge distance |
0.84m |
|
bucket indicator |
yes |
|
maximum articulated height of bucket |
3.4m |
|
digging depth |
84mm |
|
backacter bucket capacity |
0.3m3 |
|
backacter discharge height |
3.67m |
|
maximum digging depth |
4.13m |
|
bucket slewing angle |
180° |
|
bucket stick revolving radian |
180° |
|
maximum puling force |
42KN |
|
enging |
|
|
model |
DONGFANGHONG/ R4105 OR WEICHAI/R4105 |
|
type |
inline,directinjection, four-stroke,liquid cooled |
|
Cylinder internal diameter*stroke |
4105x125mm |
|
rated power |
55KW |
|
minimum fuel consumption |
239g/kw.h |
|
maximum torque |
600NM |
|
displacement |
4.33L |
|
steering system |
|
|
type |
articulated hydraulic steering |
|
model of tuming control valve |
YSF25S-00 |
|
model of steering control valve |
BZZ5-250 |
|
steering angle |
36.5±1° |
|
minimum turning radius |
5862mm |
|
system pressure |
20Mpa |
|
transmission system |
|
|
model ofhydraulic pump |
CBGJ2040/2040 |
|
type |
duplex gears pump |
|
Motor model |
A6V80HA2FZ1027 |
|
type |
swash late operated, axial piston |
|
model of shuttle valve |
XQ20-00 |
|
type of gearbox |
manually shifted |
|
gear |
2gears ahead,2gears astem |
|
maximum speed |
20Km/h |
|
axles |
|
|
main transmission type |
double reduction |
|
wheel reduction type |
single wheel reduction |
|
wheel |
|
|
tire size |
16/17-20 |
|
front wheel pressure |
0.22Mpa |
|
rear wheel pressure |
0.20Mpa |
|
service braking |
air over hydraulic caliper disc brake parking |
|
emergency brake |
flexible shaft operated external drum |
|
hydraulic system |
|
|
folw |
140L/min |
|
bucket digging capacity |
46.5KN |
|
bucket stick digging capacity |
31KN |
|
bucket hydraulic translation function |
yes |
|
bucket lift time |
4.88s |
|
bucket lower time |
3.00s |
|
bucket discharge time |
1.10s |
|
|
. |
|
|
|
|
|
|
|
|
|
|
|
four-wheel drive whole hydraulic system |
||
