50 hp Greenhouse tractor

Name: 50 hp Greenhouse tractor
Brand: XIAER
Price: Negotiable

FOB Price

Negotiable / Set

1 Set(Min.Order)

Product Details

1. garden tractor
2. 50 hp, 4 wd

Greenhouse tractor

1. garden tractor
2. 50 hp, 4 wd

Model			TH-500	TH-504
Type			4*2 wheeled type	4*4 wheeled type
	Length		3100	3100
	Width		1280	1280
	Height		1260	1260
Dimensions	Trend	Front wheel	960 adjustable	1005
of the tractor		Rear wheel	1000 adjustable	1000
(mm)	Wheel base		1820	1820
	Min ground clearance		240mm	220mm
Dry mass(kg)			1215	1410
	Model		JD4100	JD4100
	Type		water-cooled,in-line, four-stroke	water-cooled,in-line, four-stroke
Engine	Rated power(kw)		36.8	36.8
	Rated power(r/min)		2300	2300
	Fuel		Diesel	Diesel
Tyre	Front wheel		500-14	600-12
Tyre	Rear Wheel		950-20	950-20
Clutch			dry-friction,one-stage	dry-friction,one-stage
Steering			Cycloid rotary valve style	Cycloid rotary valve style
Transmission box			spur gear,plane compound 4*2	spur gear,plane compound 4*2
Suspension Type			Post 3-point linkage, Catalogue 1	Post 3-point linkage, Catalogue 1
PTO	Type and recv		Semi-independent 540/720	Semi-independent 540/720
PTO	Spline size		F35 rectangel spline with 6 teeth	F35 rectangel spline with 6 teeth

Weifang Xiaer Imp. & Exp. Co., Ltd.: Contact nameRicardo Liu; Phone86-536-8577558; AddressNo.19, Fushou West Street Weifang,Shandong
