Automatic Counting and Filling Machine

Automatic Counting and Filling Machine thumbnail-1
Automatic Counting and Filling Machine photo-1
US$ 6,000 - 10,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Application:
Food, Commodity, Medical, Chemical, Other, Food, Commodity, Medical, Chemical, Machinery & Hardware
Packaging Type:
Cans, Bottles
Contact Supplier Request Quote Chat Now
Zhengzhou Longer Machinery Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Tianjin Port/Qingdao Port
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Application Food, Commodity, Medical, Chemical, Other, Food, Commodity, Medical, Chemical, Machinery & Hardware
Packaging Type Cans, Bottles
Packaging Material Plastic, Glass
Automatic Grade Automatic
Driven Type Electric
Voltage 220V
Power 0.8KW
Place of Origin Henan, China
Brand Name LONGER
Model Number LGSL-50
Dimension(L*W*H) 2400*1300*1700mm
Weight 240KG
Certification ISO 9001:2002
After-sales Service Provided Engineers available to service machinery overseas

Specifications

automatic counting and filling machine
1,Bottle range:15-500ml
2,Productivity :10-50bot/min
3,Off-chip standard :3-20mm

automatic counting and filling machine





Description of the automatic counting and filling machine:





The counting machine is mainly used in food ,medical industries, it can automatically count particle



The transmission wheel is driven by the main drive motor through triangular belt .The stepless speed

regulation controls the speed .it adjust the speed of the filling tablets .Counting plate adopts FM AN

and eccentric frequency of the plates .The amplitude adjustment range of the plates will be widely .

the working speed is stable and reduce the phenomenon of filling with lack of the tablets.These are

controlled by the inverter ,the working speed is stable and reduce the phenomenon of filling with

lack of  tablets .These are controlled by the inverter .The conveyor belt is equipped with photoelectric

switch .When lack of bottle,The host automatically stop .So it doesn’t occur the phenomenon that no

bottle still fill .The machine can be linked with other machines as a production line.if the bottle can’t

stand on the belt ,then se the tube bottle counting machine.







Main technical parameter of the counting and filling machine :





Bottle range:15-500ml



Productivity :10-50bot/min



Off-chip standard :3-20mm



Power supply :220V/50Hz



Power :0.8kw



Number of pieces plate diameter:467mm(PMMA) 476(laminate)



Wight :240kg



Dimension :2400*1300*1700mm



automatic counting and filling machine
