automatic counting and filling machine
- 100 Set / Sets per Month
- Tianjin Port/Qingdao Port
- T/T Credit Card
- Cheapest Automatic Bottle Blowing Machine Prices/factory price automatic bottle shrink wrapping machine
- PET bottle making machine/nice plastic bottle making machine price/high quality plastic bottle blowing machine
- Top quality china automatic machines to make plastic bottles/bottle blowing machinery/Pet Bottles Blowing Machine 750ml
- Chinese PET water bottle blowing machine/equipment / automatic bottle Blowing machinery
- Low price Beverage drinking PET bottle blowing machinery/fully automatic pet bottle blowing machine
- high quality bottle blowing machine/automatic shrink wrapping machine/water bottle blowing machine
Product Details
Condition: | New | Application: | Food, Commodity, Medical, Chemical, Other, Food, Commodity, Medical, Chemical, Machinery & Hardware | Packaging Type: | Cans, Bottles |
Packaging Material: | Plastic, Glass | Automatic Grade: | Automatic | Driven Type: | Electric |
Voltage: | 220V | Power: | 0.8KW | Place of Origin: | Henan, China |
Brand Name: | LONGER | Model Number: | LGSL-50 | Dimension(L*W*H): | 2400*1300*1700mm |
Weight: | 240KG | Certification: | ISO 9001:2002 | After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
Specifications
automatic counting and filling machine1,Bottle range:15-500ml
2,Productivity :10-50bot/min
3,Off-chip standard :3-20mm
automatic counting and filling machine
Description of the automatic counting and filling machine:
The counting machine is mainly used in food ,medical industries, it can automatically count particle
The transmission wheel is driven by the main drive motor through triangular belt .The stepless speed
regulation controls the speed .it adjust the speed of the filling tablets .Counting plate adopts FM AN
and eccentric frequency of the plates .The amplitude adjustment range of the plates will be widely .
the working speed is stable and reduce the phenomenon of filling with lack of the tablets.These are
controlled by the inverter ,the working speed is stable and reduce the phenomenon of filling with
lack of tablets .These are controlled by the inverter .The conveyor belt is equipped with photoelectric
switch .When lack of bottle,The host automatically stop .So it doesn’t occur the phenomenon that no
bottle still fill .The machine can be linked with other machines as a production line.if the bottle can’t
stand on the belt ,then se the tube bottle counting machine.
Main technical parameter of the counting and filling machine :
Bottle range:15-500ml
Productivity :10-50bot/min
Off-chip standard :3-20mm
Power supply :220V/50Hz
Power :0.8kw
Number of pieces plate diameter:467mm(PMMA) 476(laminate)
Wight :240kg
Dimension :2400*1300*1700mm
