Manufacturer sells ZPA 3200-18 welded diode rectifier tube
Basic Product Information
... core functions,
The core function of thyristor is to control large with small control, using weak control signals at the milliampere level to accurately control the on/off of large currents of several hundred amperes, achieving safe control of weak electricity over strong electricity. It is the core power switching device in the field of power electronics.
Core control characteristics
1. It is a four layer three terminal semiconductor device that can self lock and maintain power after triggering conduction. The control electrode cannot be directly turned off, and the main circuit current needs to be lower than the maintenance current to restore the blocking state, thus achieving stable on-off control of high-power loads.
Core application value
2. With this function, it can complete controllable rectification, AC voltage regulation, contactless switching and other operations, widely used in motor speed regulation, home appliance dimming and temperature regulation, industrial heating, power system protection and other scenarios. It has no mechanical contact wear, long service life, and fast response speed.
Technical characteristics,
1. Outstanding in small control and large capability: With only milliampere level gate trigger current, it can control hundreds of amperes of main circuit large current, and the power amplification factor can reach hundreds of thousands of times, achieving efficient driving of weak electricity to strong electricity.
2. High reliability and strong environmental adaptability: After rigorous testing, it can operate stably in complex and harsh environments, significantly reducing system failure rates and ensuring continuous operation in industrial, transportation, and other scenarios.
3. Low loss and high efficiency: The optimized internal structure significantly reduces conduction loss, with a on state voltage drop of only 1-2V, high energy utilization efficiency, and excellent heat dissipation design that can maintain suitable working temperature for a long time, extending equipment life.
4. Fast response speed: Switching between switch states only takes microseconds, meeting the high real-time requirements of modern power systems and adapting to fast switching control scenarios.
5. Strong adaptability: It can be well compatible with other systems of various equipment such as locomotives and industrial automation, supporting multiple functions such as controllable rectification, AC voltage regulation, and contactless switches, covering applications in multiple fields such as power, new energy, and transportation.
In the application field, it is most commonly used in high-voltage solid-state soft start devices to achieve smooth motor start and suppress surge current. It can also be applied to power control scenarios such as metal melting, industrial heating, and power generation and distribution.
Mainly used in controllable rectification, inverter frequency conversion, high-power voltage regulation, industrial heating, high-voltage soft start and other scenarios, it is a commonly used core power device in metallurgy, rail transit, and power transmission fields.
