Hongshengjie saw blade cuts round steel pipes, sharp and fatigue resistant. The combination of high-strength backing material and fine grinding teeth is suitable for continuous batch cutting operations.
When cutting a round bar, the saw blade tooth tip needs to withstand a large radial cutting force; When cutting steel pipes, there is intermittent cutting caused by changes in wall thickness. Hongshengjie optimized the tooth profile parameters for these two working conditions separately. For large round bars with a diameter of over 50mm, it is recommended to use coarse teeth or variable tooth pitch, deep tooth grooves, and large chip space to avoid chip accumulation and increase cutting resistance. For thin-walled steel pipes with a wall thickness less than 5mm, it is recommended to use fine teeth, dense tooth spacing, and small cutting amount per tooth, which can effectively prevent pipe wall deformation or sawing. The tooth tip undergoes precision grinding, with high initial sharpness, and can quickly establish a stable cutting state upon the first cut, reducing idle grinding time.
The key to achieving anti fatigue performance lies in the selection of backing materials and heat treatment. The back material of Hongshengjie has undergone multiple bending tests and can withstand over a million bending cycles without cracking under simulated high-speed operating conditions. In practical use, when the user continuously cut 45 # steel round bars with a diameter of 80mm, a single saw blade completed the specified batch cutting task without any fracture or crack propagation caused by fatigue. The product offers standard lengths of 3505mm, 4115mm, 4650mm, etc., and supports non-standard customization, making it easy to quickly install on various sawing machines.
Hongshengjie can provide tooth pitch adaptation calculation services for users who cut round bars and steel pipes. Based on the pipe diameter, wall thickness, and material you provide, we can accurately recommend the tooth pitch and saw blade width to improve single cutting efficiency.
