12kw AC230v Rack Mount Load Bank for Data Center
Product Spotlights
According to user's load requirements, we could design various type of dry load bank systems, which composed of resistors, reactors, contactors, electrical parameter data acquisition system, automatic loading/unloading control system, protection system, heat dissipation device, auxiliary control, etc.
RongTai Power provide customization service for clients, which including voltage, power, frequency, power resolution, control mode, cooling mode, color, etc.
RongTai Power provide customization service for clients, which including voltage, power, frequency, power resolution, control mode, cooling mode, color, etc.
Negotiable
MOQ: 1 Unit (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Business Type:
Manufacturer
Year Established:
2022
Overseas Office:
Yes
Payment & Shipping
Payment Methods:
Port of Shipment:
ShangHai
Delivery Detail:
30 days
Related Products
-
Low Power Rated AC230v Rack Mount Load Bank for Data Center and Computer RoomNegotiableMOQ: 500 Units -
Newest Upgraded and Latest Design Liquid Cooling Load BankNegotiableMOQ: 1 Unit
-
8000 kw Marine Generator Test Ship Manufacturing ClientNegotiableMOQ: 1 Unit
-
8kw Portable Data Center Rack Load Bank for UPS TestingNegotiableMOQ: 500 Units
-
Data Center PDU Commissioning Rack Mount Load Bank 8kwNegotiableMOQ: 500 Units
| Technical Parameters | |
| Rated Voltage /Frequency |
AC single-phase AC230V 50/60Hz; |
| Rated power | Total load: 12kW; |
| Load Step | Resistive Load: Divided into 7 levels: A(FAN, 0.5kW, 1.5kW), B (2kW), C (2kW), D (2kW), E (2kW) and F (2kW). Note: When used below the rated voltage, the gear power decreases according to Ohm's law. |
| Power Factor | 1 |
| Load accuracy (per gear) |
±5% |
| Load accuracy (whole machine) | ±3% |
| Control power supply | Connected, the fan power is not included in the load. |
| Connection mode | Load power input -- C14 |
| Insulation Class | F |
| Duty Cycle | Continuous operation; |
| Cooling | Forced air cooling, forward wind, after the wind. |
| Casing Color | black |
| Dimension | 19 inches, 7U, approximately 431mmx500mmx311.15mm (W*D*H) |
| weight | About 35kg |
| Transportation | The front panel mounting handle is transportable, with hanging ears. |
| Operating Environment Parameter | |
| Working environment | indoor |
| Work Temperature | -20ºC~+50ºC. |
| relative humidity | ≤95%; |
| Altitude | ≤2500M |
| Atmospheric Pressure | 86~106kPa |
| Protection function | 1, short circuit, temperature, chassis grounding protection; 2. All interfaces are independent and not parallel. |
| transport | The front panel has a handle and detachable ears on both sides. |
