About the Product
Hengshui City Yike Composite Materials Co., Ltd., established in 2009, proudly presents this 5000 Gallon FRP Tank with 10mm Wall Thickness for Chemical Storage. As a reliable manufacturer with an annual export value of US$1.5–2.5 million, we specialize in producing high-quality fiberglass reinforced plastic tanks that meet the demanding needs of the global chemical industry. This tank combines superior corrosion resistance, structural integrity, and long service life, making it an ideal solution for storing aggressive chemicals, acids, alkalis, and other hazardous liquids. Our tanks are designed to withstand harsh environments while providing exceptional value for money.
Key Features & Technical Specifications
5000 Gallon Capacity – Equivalent to approximately 18,927 liters, suitable for large-scale chemical storage applications.
10mm Wall Thickness – Provides robust mechanical strength and resistance to external loads, impact, and internal pressure.
High-Quality FRP Construction – Made from premium fiberglass and thermosetting resin (e.g., vinyl ester, polyester, or epoxy) selected based on the specific chemical being stored.
Corrosion-Resistant Interior – A smooth gel coat lining prevents chemical attack and ensures easy cleaning and maintenance.
UV-Resistant Exterior – Optional UV stabilizers can be added for outdoor installations, extending the tank's lifespan.
Customizable Configurations – Available with various nozzle sizes, manways, ladders, platforms, and support saddles to match your facility layout.
Lightweight yet Strong – FRP is significantly lighter than steel or concrete, reducing transportation and installation costs.
Low Thermal Conductivity – Helps maintain stable internal temperatures for temperature-sensitive chemicals.
Long Service Life – Properly designed and maintained FRP tanks can last 20–30 years or more in suitable environments.
Technical Parameters (Table)
| Parameter | Value |
|---|---|
| Capacity | 5000 gallons (18,927 L) |
| Wall Thickness | 10 mm (0.394 inches) |
| Diameter | Customizable (typical range: 2.0–3.5 m) |
| Height | Customizable (typical range: 3.0–5.0 m) |
| Design Pressure | Atmospheric or up to 0.5 bar (customizable) |
| Design Temperature | -40°C to +80°C (depending on resin) |
| Resin System | Polyester, Vinyl Ester, Epoxy (optional) |
| Fittings | Inlet/outlet nozzles, manhole, vent, drain, etc. |
| Weight | Approx. 1,500–2,500 kg (depending on design) |
| Color | Customizable (standard: green/blue/gray) |
Advantages & Customer Benefits
Enhanced Safety – The 10mm thick wall provides excellent mechanical strength, reducing the risk of leaks or ruptures.
Chemical Compatibility – We work with our clients to select the appropriate resin and gel coat, ensuring compatibility with hundreds of chemicals, including sulfuric acid, hydrochloric acid, sodium hydroxide, and more.
Cost-Effective – Lower initial investment compared to stainless steel or lined carbon steel tanks, plus minimal maintenance over the tank's lifetime.
Easy Installation – Lightweight FRP allows for crane or forklift installation without heavy equipment, saving time and labor.
Customizable Dimensions – We can adjust diameter, height, and nozzle locations to fit your existing footprint or piping system.
Global Shipping Expertise – With over 15 years of export experience, we ensure safe packing and on-time delivery to ports worldwide, including Tianjin, Shanghai, and other major Chinese ports.
Why Choose Hengshui City Yike Composite Materials?
Since 2009, we have been dedicated to manufacturing high-performance FRP products. Our annual export value of US$1.5–2.5 million reflects the trust of customers in North America, South America, Europe, Africa, the Middle East, and Asia. We have shipped thousands of tanks to diverse industries, including chemical processing, water treatment, oil & gas, and agriculture. Our team ensures strict quality control at every stage — from raw material inspection to final pressure testing. We also offer comprehensive after-sales support, including installation guidance and technical documentation. Contact us today to discuss your specific chemical storage requirements and receive a customized quotation. Let our expertise safeguard your operations.
Frequently Asked Questions (FAQ)
Q: What chemicals can this 5000 gallon FRP tank store?
A: It can store a wide range of chemicals, including acids, alkalis, salts, and organic solvents. The exact resin system (polyester, vinyl ester, or epoxy) is selected based on the specific chemical and operating temperature. Please provide your chemical list for a compatibility assessment.Q: Is the 10mm wall thickness sufficient for underground installation?
A: The 10mm wall provides good structural strength for above-ground installations. For underground burial, we recommend additional reinforcement or a thicker wall (e.g., 12–15mm) to withstand soil loading. Our engineers can design the tank accordingly.Q: Can you customize the tank dimensions (height, diameter)?
A: Yes, absolutely. The 5000 gallon capacity can be achieved with different height-to-diameter ratios to suit your space constraints. We provide CAD drawings for approval before production.Q: What certifications does your FRP tank have?
A: While we do not hold specific international certifications like ASME or ISO on the product label, our manufacturing process follows strict internal quality standards. Certifications can be provided upon request for specific projects (e.g., third-party inspection reports).Q: How long does it take to manufacture and deliver?
A: Typical lead time is 30–45 days after order confirmation and design approval. Shipping time varies by destination (e.g., 20–35 days by sea). We can expedite for urgent orders.Q: How do you ensure the tank is leak-proof?
A: Every tank undergoes a 100% hydrostatic or pneumatic pressure test before shipment. We also perform visual inspection and holiday detection on the gel coat lining to ensure integrity.Q: What maintenance is required for this FRP tank?
A: Minimal maintenance is needed. Periodically inspect the exterior for any damage, clean the interior if changing chemicals, and check gaskets/seals on manways and nozzles. The gel coat protects the fiberglass from chemical attack.Q: Can you provide fittings like flanges, vents, and level indicators?
A: Yes, we offer a full range of optional fittings, including stainless steel or FRP flanges, vents, overflow pipes, manholes, and mountings for level transmitters. All are customizable to your specifications.
