ABB Bailey INFI 90 DCS Core Solution – Complete Controller, Bus Adapter & Redundancy Cable Kit
The ABB Bailey INFI 90 DCS Core Solution is a comprehensive, pre-matched set of three essential components engineered to build, upgrade, or maintain the heart of your ABB Bailey INFI 90, Symphony Plus, or Harmony Rack distributed control system (DCS). This integrated kit combines the central processing power of the BRC300 bridge controller, the high-speed communication backbone of the PBA200 processor bus adapter, and the fail-safe synchronization of the PMKHRMBRC3000A redundancy cable – delivering a turnkey core solution for power generation, petrochemical, oil & gas, metallurgy, and water treatment facilities worldwide.
Complete Kit Component Overview
| Model | Product Name | Core Function | Key Specification |
|---|---|---|---|
| P-HC-BRC30000000 | BRC300 Harmony Bridge Controller | Central CPU executing control logic, PID, and SOE; bridges field I/O to INFI-NET | 32-bit ColdFire @160MHz, 257 MIPS, 8MB SDRAM |
| PHCBRCPBA20000 | PBA200 Processor Bus Adapter | High-speed hood-style adapter linking BRC300 to I/O racks via dual redundant processor bus | Dual-bus support, 5 VDC @0.12A, hot-swappable |
| PMKHRMBRC3000A | Redundancy Cable Assembly | Physical cable synchronizing primary and backup BRC controllers with near-zero latency | 4 cm length, 12-core twisted-pair, foil + braid shielding |
Detailed Product Descriptions
1. P-HC-BRC30000000 – BRC300 Harmony Bridge Controller
The BRC300 (also known as SPBRC300) is the central CPU module that serves as the "brain" of the process control station (FCS). It performs two critical functions within the DCS architecture:
Control Processing – Executes control logic, collects I/O data, performs PID calculations, and manages sequence of events (SOE) recording with ≤2ms resolution
Network Bridging – Transmits field data to the INFI-NET backbone while receiving and distributing upper-layer commands to field devices
Powered by a 32-bit Freescale ColdFire MCF5407 RISC processor running at 160 MHz with 257 MIPS computational performance, the module features 8MB SDRAM, 512KB NVRAM, and 2MB Flash ROM. It supports over 150 predefined ABB function codes, as well as C applications, Batch 90, and user-defined functions. The architecture supports redundant controllers, communications, I/O, and power – primary-to-backup switchover occurs in milliseconds without process interruption.
Important Note: This model has been officially discontinued by ABB and is available as New Surplus inventory. Please confirm firmware version compatibility with your existing system before ordering.
2. PHCBRCPBA20000 – PBA200 Processor Bus Adapter
The PBA200 is a critical processor bus adapter designed for the Symphony Plus Harmony Rack (HR Series) architecture and ABB Bailey INFI 90 control systems. This hood-style PBD assembly enables high-speed, deterministic communication between BRC300/BRC400/BRC410 controllers and distributed I/O modules.
Built on the PBA800 distributed architecture, the PBA200 allows bridge controllers to access remote intelligent I/O racks with high-deterministic serial communication. This eliminates kilometers of analog signal cables from field to control room, significantly reducing cabling costs and installation time. The serial communication link provides microsecond-level latency – essential for critical closed-loop control applications such as CCS (Coordinated Control Systems) and DEH (Digital Electro-Hydraulic control).
Key technical specifications:
Operating Voltage: 5 VDC
Current: 0.12 AMP
Redundancy: Dual processor bus support (maintains 99.99% system availability)
Hot-Swappable: Field-replaceable during system operation without controller reboot
Dimensions: 152 × 76 × 152 mm
Weight: 231g
The PBA200 seamlessly connects legacy Bailey INFI-90 systems to modern networks, enabling data sharing, remote monitoring, and enhanced control capabilities. It is fully compatible with BRC300/400/410 series bridge controllers and various I/O modules (IMSED01, SPSED01, etc.), requiring no third-party gateways.
3. PMKHRMBRC3000A – Factory-Terminated Redundancy Cable
The PMKHRMBRC3000A is a factory-terminated, high-reliability redundancy cable assembly engineered specifically for ABB Bailey INFI 90 and Symphony Harmony DCS systems. This prefabricated cable provides the critical physical interconnection for redundant processor pairs, enabling near-zero latency state synchronization between primary and backup controller modules.
The cable serves as the dedicated physical mirror path linking primary and backup module nodes – ensuring complete memory image alignment across the processor pair. The standby controller assumes control within milliseconds during fault scenarios without process interruption.
Technical specifications:
Cable Length: 4 cm (0.04 meters)
Conductor: 12 × 7/0.25 mm tinned copper (6 twisted pairs)
Impedance: 100 Ω ±10% @ 1 MHz
Shielding: Foil + Braid (EMI/RFI protection)
Voltage Rating: 30 V RMS working
Current Rating: 1 A per conductor @ 30°C
Operating Temperature: -40°C to +80°C
Compatible Modules: BRC300, BRC400, BRC410, NPM22, RIO22, HPG800
System Compatibility: Bailey INFI 90, Symphony Harmony DCS
The robust foil and braid shielding effectively minimizes EMI from nearby high-voltage switchgear, ensuring error-free state synchronization even in harsh industrial environments. As a passive conductor loop, it adds zero latency and requires no firmware or software configuration.
Why Choose This Kit?
One-Stop Solution – All three critical components in a single, matched set, eliminating compatibility risks and separate sourcing
Proven Redundancy – Hot-standby controller, dual-bus I/O, and dedicated sync cable deliver 99.99% availability
Legacy-to-Modern Bridge – Extend the life of your Bailey INFI 90 or Symphony Plus system with new-old-stock genuine parts
Optimized for Power & Process – Ideal for turbine control, boiler management, refinery automation, and any application demanding deterministic control and rapid failover
100% Genuine & Warranted – Each component is sourced from ABB authorized channels and backed by a 12-month warranty
Applications
Power Generation – Steam and gas turbine governing, boiler combustion control, plant-wide DCS upgrades (50-1000 MW)
Oil & Gas – Pipeline SCADA, refinery process control, emergency shutdown systems
Chemical & Petrochemical – Batch reactors, continuous distillation, safety interlocks
Metallurgy & Mining – Rolling mill control, furnace temperature control, conveyor automation
Water & Wastewater – Pump station control, treatment plant automation (10-500 MGD)
Quality Assurance & Service
✅ 100% Brand New & Genuine – All items are new surplus or factory-sealed, never refurbished
✅ One-Year Quality Warranty – Comprehensive coverage against defects in materials and workmanship
✅ Competitive Pricing – Direct sourcing from our global supply chain passes savings to you
✅ Fast Delivery – In-stock items dispatched within 1–3 working days
✅ Expert Technical Support – Our DCS specialists assist with selection, compatibility checks, and installation guidance
