Hengshui Ruibin New Materials LLC – your trusted partner in cable management solutions. As a professional manufacturer established in 2019, we have dedicated ourselves to producing high-quality cable support systems for global markets. Our Fiber Optic Cable Tray Ladder with PVC Raceway is a carefully engineered product designed to meet the demanding needs of fiber optic and data cable installations. By combining a sturdy ladder tray structure with a smooth PVC raceway, we offer a complete solution that protects sensitive cables while ensuring easy routing and maintenance. This product is ISO9001 certified and has been exported to over 10 regions worldwide, including North America, Europe, and Southeast Asia, demonstrating its reliability and compliance with international standards.
Our factory spans 1,000–3,000 square meters and employs 101–200 skilled workers, ensuring consistent quality and timely delivery. With an annual export value of US$2.5–5 million, we have built a strong supply chain capable of handling large-scale orders. The following sections will provide a detailed overview of the product's features, specifications, and benefits.
Product Overview
The Fiber Optic Cable Tray Ladder with PVC Raceway is a dual-purpose cable management system. It consists of a robust ladder-type tray made of steel or aluminum (optional), with a built-in PVC raceway channel that runs along the side or bottom of the tray. This design allows installers to separate fiber optic cables from power cables, reducing signal interference and improving safety. The PVC raceway provides a smooth, non-abrasive surface that prevents micro-bending and damage to delicate fiber strands.
- Rugged Ladder Structure: Provides high load-bearing capacity (up to 150 kg/m) and excellent ventilation, reducing heat buildup.
- PVC Raceway Integration: Seamlessly attached to the tray, offering a dedicated channel for fiber optic cables with a smooth interior radius.
- Corrosion Resistance: Hot-dip galvanized finish (or pre-galvanized) ensures long service life in harsh environments, including outdoor and industrial settings.
- Easy Installation: Pre-assembled sections with standard lengths (3m or 6m) and simple coupling systems for fast on-site assembly.
- Customizable Options: Available in various widths (200mm to 800mm), heights (50mm to 100mm), and colors (RAL codes). PVC raceway dimensions can be tailored to match specific cable quantities.
Technical Specifications
| Parameter | Value |
|---|---|
| Material (Tray) | Steel (Q235) / Aluminum 6063 |
| Surface Finish | Hot Dip Galvanized (HDG) / Pre-Galvanized / Powder Coated (optional) |
| Standard Width | 200mm, 300mm, 400mm, 600mm, 800mm |
| Standard Height | 50mm, 75mm, 100mm |
| Section Length | 3m / 6m (custom lengths up to 9m) |
| PVC Raceway Material | PVC (UL 94 V-0 flame retardant, halogen-free optional) |
| PVC Raceway Dimensions | Width: 50mm-150mm; Depth: 30mm-80mm |
| Load Capacity | Up to 150 kg/m (for 3m span, steel tray) |
| Operating Temperature | -40°C to +70°C (PVC raceway); -40°C to +120°C (metal tray) |
| Certification | ISO9001:2015 |
Key Benefits for Your Business
- Enhanced Cable Protection: The PVC raceway ensures that fiber optic cables are not crushed or pinched by the metal tray, maintaining signal integrity and reducing installation failures.
- Time & Cost Savings: Prefabricated sections and integrated design reduce on-site labor. No need to purchase separate raceways and fasteners – one product does it all.
- Versatile Application: Suitable for data centers, telecommunication rooms, industrial plants, commercial buildings, and outdoor fiber runs. The corrosion-resistant finish makes it ideal for harsh environments.
- Flexible Customization: We offer custom lengths, widths, and colors, as well as special PVC raceway configurations (e.g., with dividers or multiple channels). OEM/ODM orders are welcome.
- Compliance & Safety: Manufactured under ISO9001 quality management system. The PVC raceway meets UL 94 V-0 flame retardancy requirements, contributing to fire safety in cable pathways.
Why Choose Hengshui Ruibin New Materials LLC?
Since our founding in 2019, we have grown into a reliable manufacturer with a 1,000–3,000 square meter factory and a team of 101–200 experienced professionals. Our annual export value of US$2.5–5 million reflects our strong presence in markets such as North America, South America, Eastern Europe, Southeast Asia, Africa, Oceania, the Middle East, Eastern Asia, Western Europe, Central America, Northern Europe, South Asia, and the domestic market. We ship from the ports of Tianjin and Qingdao, ensuring efficient logistics to global destinations.
Our products are backed by ISO9001 and ISO9000 certifications, guaranteeing consistent quality control from raw material procurement to final inspection. We have a dedicated R&D team that continuously improves our designs to meet evolving industry needs. Whether you require standard sizes or custom solutions, we are committed to delivering products that exceed your expectations.
Contact us today to discuss your cable management requirements. With our competitive pricing, fast lead times, and professional after-sales support, we are confident that our Fiber Optic Cable Tray Ladder with PVC Raceway will be the perfect solution for your projects. Request a quote or sample to experience the quality firsthand.
Frequently Asked Questions (FAQ)
-
Q: What is the main advantage of having a PVC raceway integrated with the ladder tray?
A: The PVC raceway provides a smooth, non-abrasive channel specifically for fiber optic cables, protecting them from sharp edges and metal contact. It also helps separate fiber cables from power cables, reducing electromagnetic interference and simplifying cable management. -
Q: Can this product be used outdoors?
A: Yes, when ordered with a hot-dip galvanized finish, the metal tray is highly corrosion-resistant and suitable for outdoor use. The PVC raceway is UV-stabilized (optional) for extended sunlight exposure. Please specify your outdoor requirements when ordering. -
Q: What materials are available for the tray?
A: We offer both steel (Q235) and aluminum (6063) options. Steel provides higher load capacity, while aluminum is lighter and offers natural corrosion resistance. Both can be finished with hot-dip galvanizing or powder coating. -
Q: What is the maximum load capacity?
A: For a standard steel tray with 3m span, the load capacity can reach up to 150 kg/m. Actual capacity depends on the width, height, and material. Please refer to our load tables for specific configurations. -
Q: Can I get custom lengths or colors?
A: Absolutely. We offer custom lengths from 1m to 9m, and custom RAL colors for powder coating. PVC raceway dimensions can also be adjusted. Minimum order quantities may apply for customizations. -
Q: Does the PVC raceway meet fire safety standards?
A: Yes, our standard PVC raceway is UL 94 V-0 rated (flame retardant). Halogen-free and low-smoke PVC options are available upon request for environments with strict fire codes. -
Q: How is the product packaged for export?
A: Products are packed in bundles with steel strapping, wrapped in waterproof paper, and placed on wooden pallets or in steel crates to prevent damage during transit. We also offer custom packaging per customer requirements. -
Q: What is the typical lead time?
A: For standard sizes, lead time is 15–20 working days after deposit. Custom orders may take 25–30 working days. We ship from Tianjin or Qingdao ports.
