Siemens ALM Module 6SL3130-7TE21-6AA4 SINAMICS Power Supply
SINAMICS S120 Regulated Power Supply Module Input: 3AC 380-480V, 50/60Hz Output: 600V DC, 27A, 16kW Structure: Book size Internal air cooling Includes Drive-CLiQ cable.
In stock! In stock! In stock!
Supplied by Siemens agent. Genuine products with one-year warranty.
Shanghai Binqin Electrical Technology Co., Ltd.
Posted by: Kang Kui (Sales Manager)
The company is a Siemens agent. A large quantity of Siemens modules are in stock. Free shipping by SF Express, including tax.
Feel free to consult me for sales, repair, and commissioning if needed.
Featured products
Get inspired by our innovative product range
All
Variable frequency drives
Motors
Newly added
G220_CPD
High-performance variable frequency drive
SINAMICS G220 Clean Power
The ultimate low-harmonics drive
Configuration
SINAMICS G220 Clean Power: Built-in compact unit with built-in operation panel and low-harmonics technology
Power supply voltage / Power kW (hp):
3AC 380 to 500 V, IP20: 7.5 to 160 kW (10 to 250 hp)
3AC 380 to 500 V, IP55: 7.5 to 110 kW (10 to 150 hp)
Control mode: V/f (linear, square law, FCC, ECO), vector control with/without encoder (VC, SLVC)
Protection class: IP20 / UL open type, IP55 / UL type 12
Energy recovery: No
Safety functions: Standard: STO, SS1, SMT (Requires option module OM-SMT)
Extended: SS1E, SS2, SS2E, SOS, SLS, SLA, SSM, SDI (SIL 3, PL e, Category 4 HW & PROFISafe)
ATEX: ATEX-certified PTC thermistor input for explosion-proof motors (SMT)
Communication: PROFINET (RT / IRT, MRP & S2 redundancy), EtherNet/IP, Modbus TCP/IP, PROFIBUS DP, Modbus RTU
Commissioning / Engineering configuration:
Newly added
G220
High-performance frequency converter
SINAMICS G220
Innovation in every detail. SINAMICS G220 – the variable frequency drive for all industries
Configuration
SINAMICS G220: Built-in compact unit with built-in operation panel
Supply voltage/power kW (hp): 3AC 200 to 240 V IP20 / IP55: 0.55 to 55kW (0.75 to 75 hp)
3AC 380 to 500 V IP20: 1.1 to 160kW (1.5 to 250 hp)
3AC 380 to 500 V IP55: 1.1 to 110 kW (1.5 to 150 hp)
Control mode: V/f (linear, square law, FCC, ECO), vector control with/without encoder (VC, SLVC)
Protection level: IP20 / UL open type, IP55 / UL type 12
Energy recovery: No
Security features: Standard: STO, SS1, SMT (Optional module OM-SMT is required)
Extended: SS1E, SS2, SS2E, SOS, SLS, SLA, SSM, SDI
(SIL 3, PL e, Category 4 HW & PROFISafe)
ATEX-certified PTC thermistor input for explosion-protected motors (SMT)
Communication: PROFINET (RT / IRT, MRP & S2 redundancy), EtherNet/IP, Modbus TCP/IP, PROFIBUS DP, Modbus RTU
Debugging/Engineering configuration: Integrated web server; SINAMICS Startdrive; TIA Selection Tool, SINAMICS Smart Adapter for Wi-Fi wireless connection
Newly added
S220
Servo frequency converter
SINAMICS S220
Performance meets Perfection. Powerful. Precise. Progressive.
Configuration
SINAMICS S220:
Supply voltage/Power kW: 3 AC 380 - 480 V / 16kW – 55kW
Debugging/Engineering configuration: Startdrive
Protection class: IP20
Energy recovery: Yes
Safety function: SIL 3, PL e.
Communication: PROFINET
G120
Standard performance frequency converter
SINAMICS G120
Multifunctional. Combinable. Safe. SINAMICS G120 - the multifunctional frequency converter for your diverse tasks.
Configuration
SINAMICS G120 PM240-2: Power module of G120 modular system
Power supply voltage/Power kW (hp):
1 AC 200 - 240 V/0.55 kW - 4 kW (0.75 to 5 hp)
3 AC 200 - 240 V / 5.5kW - 55 kW (7.5 to 75 hp)
3 AC 380 - 480 V/0.55 kW - 250 kW (0.75 to 400 hp)
3 AC 500 - 690 V/11 kW - 250 kW (10 to 250 hp)
Energy recovery: None
PM250: Power module of the G120 modular system
Supply voltage/Power kW (hp):
3 AC 380 - 480 V/7.5 kW - 90 kW (10 to 125 hp)
Energy recovery: Yes
Torque range: n.a.
Commissioning/Engineering configuration: Optional operating panel and web server functions (options required) assigned to different control units; SINAMICS Startdrive; STARTER/SIZER; TIA Selection Tool
Protection class: IP20
Safety functions: Suitable for Safety Integrated; Safety functions assigned to different control units
Communication: Fieldbus interfaces assigned to different control units
G120C
Standard performance frequency converter
SINAMICS G120C
Versatile. User friendly. Compact. The frequency converter with optimum functionality.
Configuration
SINAMICS G120C: Built-in unit (compact)
Supply voltage/Power kW (hp):
3AC 380 to 480 V: 0.55 to 132 kW (0.75 to 150 hp)
Control mode: V/f (linear, square law, FCC, ECO), Sensorless vector control (SLVC)
Protection class: IP20/UL Open type
Energy recovery: None
Safety functions: STO
Communication: PROFINET / Ethernet/IP, PROFIBUS DP, USS/Modbus RTU
New addition
1FK2
Servo motor SIMOTICS S
Synchronous motor SIMOTICS S-1FK2
Dynamic and compact solution
Configuration
SIMOTICS S-1FK2, for SINAMICS S120 and SINAMICS S210
Power supply voltage:
1/3AC 200-240V, for SINAMICS S210
3AC 380-480V, for SINAMICS S210 and SINAMICS S120
Rated speed: 1500 r/min to 6000 r/min
Speed: 8 000 r/min
Static torque: 0.16 Nm to 50 Nm
Rated power: 0.1 kW to 7.1 kW
Cooling method: Self-cooling
Shaft height: SH20 to SH100
Protection class: IP64, IP65
Newly added
1FT2
Servo motor SIMOTICS S
Servo motor SIMOTICS S-1FT2
Optimizable motor solution
Configuration
SIMOTICS S-1FT2, for SINAMICS S120 and SINAMICS S210
Power supply voltage:
1/3AC 200-240V, for SINAMICS S210
3AC 380-480V, for SINAMICS S210 and SINAMICS S120
Rated speed: 1500 r/min to 6000 r/min
Speed: 8000 r/min
Static torque: 0.16 Nm to 50 Nm
Rated power: 0.1 kW to 7.1 kW
Cooling method: Self-cooling
Shaft height: SH20 to SH100
Protection class: IP64, IP65
Newly added
S_S210
Servo frequency converter
SINAMICS S210 and SIMOTICS S-1FT2/1FK2
Versatile. Precise. Safe. The new servo drive SINAMICS S210 - More features, more possibilities
