2 Way V Port Metal Ball Valve with ISO5211 Direct Mounting Pad
Precision Flow Control Solution for Industrial Automation Systems
The 2 Way V Port Metal Ball Valve with ISO5211 Direct Mounting Pad is specifically designed for applications requiring both reliable shut-off performance and precise flow regulation. Unlike conventional full-port ball valves, the precision-engineered V-shaped ball opening provides excellent throttling characteristics, allowing accurate control of liquid, gas, steam, and abrasive media.
Manufactured according to ASME B16.34 standards and tested in compliance with API 598, this valve offers exceptional durability, leak-tight sealing performance, and compatibility with modern automation systems through its standardized ISO5211 actuator mounting platform.
Widely used in oil & gas, petrochemical, chemical processing, power generation, water treatment, and industrial automation industries, this valve delivers stable performance under demanding operating conditions.
Key Features
Precision V-Port Flow Control
The specially designed V-shaped ball opening provides superior flow modulation compared to standard ball valves. It delivers nearly linear flow characteristics, making it suitable for:
· Chemical dosing systems
· Process control applications
· Flow metering systems
· Industrial automation loops
· Mixing and blending processes
ISO5211 Direct Mounting Platform
The integrated ISO5211 mounting pad allows direct installation of:
· Pneumatic actuators
· Electric actuators
· Hydraulic actuators
No additional brackets or couplings are required, reducing installation costs and simplifying maintenance.
Heavy-Duty Metal Construction
Manufactured using premium-grade materials such as:
· CF3M (316L Stainless Steel)
· CF8M (316 Stainless Steel)
· CF8 (304 Stainless Steel)
· WCB Carbon Steel
These materials provide excellent mechanical strength and corrosion resistance in demanding industrial environments.
Excellent Sealing Performance
Available with:
· SS316 + Stellite Seats
· PTFE Seats
The valve ensures reliable shut-off performance while maintaining long service life under high-temperature and high-pressure conditions.
Multiple Pressure Classes Available
Suitable for various industrial systems:
· Class 150
· Class 300
· PN16
This flexibility allows seamless integration into both European and American piping systems.
Automation Ready
The ISO5211 mounting interface supports seamless integration into:
· SCADA systems
· PLC control systems
· DCS process control systems
· Remote monitoring platforms
Technical Specifications
Parameter |
Specification |
Valve Type |
2 Way V Port Metal Ball Valve |
Design Standard |
ASME B16.34 |
Testing Standard |
API 598 |
Pressure Rating |
Class 150, Class 300, PN16 |
Size Range |
2" – 8" |
Connection Type |
Flanged |
Mounting Standard |
ISO5211 |
Seat Material |
SS316 + Stellite, PTFE |
Body Material |
CF3M, CF8M, CF8, WCB |
Operation |
Manual, Pneumatic, Electric |
Flow Characteristic |
V-Port Linear Control |
Application |
Flow Regulation & Shut-Off |
Available Materials
Component |
Material Options |
Body |
WCB, CF8, CF8M, CF3M |
Ball |
Precision Machined Metal V-Port Ball |
Stem |
Stainless Steel |
Seat |
SS316 + Stellite, PTFE |
Mounting Pad |
ISO5211 Standard |
Actuation Options
Manual Operation
Ideal for general industrial service where local operation is required.
Advantages
· Simple operation
· Low maintenance
· Cost-effective solution
Pneumatic Actuator
Suitable for automated process control applications requiring rapid response.
Advantages
· Fast operation
· Reliable performance
· Suitable for hazardous environments
· Easy integration with automation systems
Electric Actuator
Recommended for precision flow control and remote operation applications.
Advantages
· Accurate positioning
· Remote monitoring capability
· SCADA compatibility
· Intelligent control functions
Typical Applications
Oil & Gas Industry
· Pipeline flow regulation
· Storage terminal systems
· Refinery process control
· Gas distribution networks
Petrochemical Industry
· Process fluid control
· Chemical transfer systems
· Catalyst handling operations
· Hydrocarbon processing
Chemical Processing
· Corrosive media handling
· Chemical dosing systems
· Reactor feed control
· Process automation
Water Treatment Plants
· Water distribution systems
· Filtration units
· Chemical injection systems
· Wastewater treatment facilities
Power Generation
· Cooling water systems
· Auxiliary process pipelines
· Steam control applications
Why Choose Our V Port Metal Ball Valve?
International Standard Compliance
Manufactured according to ASME B16.34 and tested to API 598 standards.
Superior Flow Control Accuracy
The precision V-port design provides excellent throttling performance and stable flow characteristics.
Automation-Friendly Design
ISO5211 mounting platform simplifies actuator installation and future upgrades.
Long Service Life
Robust metal construction ensures outstanding resistance to wear, corrosion, pressure, and temperature.
Global Export Experience
Widely supplied to customers in North America, Europe, Southeast Asia, the Middle East, and South America.
Competitive Factory Pricing
Direct manufacturer support with reliable quality control and international project experience.
Frequently Asked Questions (FAQ)
What is the advantage of a V port ball valve over a standard ball valve?
A V port ball valve provides precise throttling and flow regulation capabilities, while standard ball valves are primarily designed for on/off service.
What actuators can be installed on this valve?
The ISO5211 mounting pad supports pneumatic, electric, and hydraulic actuators from most international brands.
Which seat material should I choose?
PTFE seats are suitable for general industrial applications and corrosive media, while SS316 + Stellite seats are recommended for high-temperature, high-pressure, and abrasive service conditions.
Is this valve suitable for automated systems?
Yes. The ISO5211 direct mounting platform allows easy integration with PLC, DCS, and SCADA automation systems.
Which material is best for corrosive media?
CF8M (316 SS) and CF3M (316L SS) are recommended for corrosive chemical applications and marine environments.
