As a leading manufacturer with over a decade of expertise, Qingdao Yongke Machinery Co., Ltd. proudly introduces our advanced Servo-Driven Structured Wall Pipe Machine. Engineered for precision and flexibility, this machine is designed to meet the evolving demands of the global pipe production industry. Our commitment to innovation and quality, backed by ISO certifications, ensures that you receive equipment that enhances your production efficiency and product quality, helping you stay competitive in markets from North America to Southeast Asia.
This state-of-the-art machine represents a significant leap in pipe extrusion technology. It is specifically engineered for the high-volume production of structured wall pipes, which are essential for modern drainage, sewerage, and cable protection systems. The core of its design is the integration of servo-driven technology, which provides unparalleled control over every stage of the extrusion process.
- Precision Servo Drive System: Unlike traditional hydraulic systems, our servo-driven actuators offer exceptional accuracy and repeatability. This results in consistent wall thickness, precise corrugation profiles, and minimal material waste. The system is highly responsive, allowing for quick adjustments and stable operation at various production speeds.
- Fully Customizable Profile Molds: We understand that project requirements vary. Our machine is compatible with a wide range of customizable profile molds. Whether you need single-wall corrugated, double-wall, or triple-wall structured pipes with specific rib patterns and diameters, our engineering team can develop the perfect mold solution for your application.
- Intelligent PLC Control with HMI: The entire production line is managed by a sophisticated Programmable Logic Controller (PLC) paired with a user-friendly touch-screen Human-Machine Interface (HMI). Operators can easily set parameters, monitor real-time production data, diagnose issues, and store recipes for different product types, ensuring quick changeovers and reduced downtime.
- Robust and Stable Construction: Built within our 10,000-30,000 square meter facility, the machine features a heavy-duty welded steel frame. This robust construction provides the necessary stability and vibration damping for high-precision extrusion, ensuring long-term reliability and consistent performance even under continuous operation.
- Efficient Multi-Stage Cooling System: Proper cooling is critical for achieving the desired mechanical properties and dimensional stability in structured wall pipes. Our machine incorporates a multi-stage cooling system, typically combining vacuum calibration and spray water cooling, to ensure uniform and controlled cooling throughout the pipe's complex profile.
The technical specifications of the machine can be tailored to your specific output goals and material types. Below is a general overview of configurable parameters:
| Parameter | Description / Range |
|---|---|
| Suitable Pipe Materials | HDPE, PP, PVC, and other thermoplastic polymers |
| Pipe Diameter Range | Customizable, commonly from 110mm to 1200mm |
| Wall Structure | Single-wall corrugated, double-wall, triple-wall profiles |
| Drive Power | Configured based on pipe size and output requirements |
| Control System | PLC (Siemens/Mitsubishi optional) with color touch HMI |
| Cooling Length | Customizable vacuum and spray cooling tanks |
By investing in our Servo-Driven Structured Wall Pipe Machine, you gain a powerful tool for your business. The benefits are clear: higher production efficiency due to faster cycle times and automation, superior product quality with consistent dimensions and strength, significant material savings from precise extrusion control, and the flexibility to produce a diverse product portfolio with quick mold changes. This allows you to respond swiftly to market opportunities in infrastructure, construction, and telecommunications.
With an annual export value exceeding US$1 million and a strong presence across six continents, Qingdao Yongke Machinery has proven its capability to deliver reliable industrial solutions. Our certifications in Quality (ISO9001), Environment (ISO14000), and Occupational Health & Safety (OHSAS18001) are not just badges; they are a testament to our systematic approach to manufacturing excellence. Every machine is backed by our team of 51-100 dedicated professionals, from engineering to after-sales support. Choose a partner with a global footprint and a solid reputation. Contact us today to discuss how this customizable, high-performance pipe machine can be configured to drive the growth and profitability of your operations.
Frequently Asked Questions (FAQ)
Q1: What is the main advantage of a servo-driven system over a conventional hydraulic system in this machine?
A: Servo-driven systems provide superior precision, energy efficiency, and cleaner operation. They allow for exact control of movement and force, resulting in more consistent pipe dimensions, smoother surfaces, and lower power consumption compared to hydraulic systems, which can have issues with oil leaks and maintenance.
Q2: How customizable are the profile molds, and what is the lead time for a new mold?
A: The molds are highly customizable. You can specify the pipe diameter, corrugation profile (shape, height, pitch), and wall structure (single/double/triple). Lead time for a new mold depends on complexity, typically ranging from 4 to 8 weeks. Our engineering team will work closely with you on the design.
Q3: What kind of after-sales support and training do you provide?
A: We provide comprehensive support including installation guidance (on-site or remote), detailed operational training for your technicians, a thorough maintenance manual, and a warranty period. Spare parts are readily available from our Qingdao factory and can be shipped globally via the Port of Qingdao.
Q4: Can this machine process recycled plastic materials?
A: Yes, the machine is designed to handle various thermoplastics, including certain grades of recycled HDPE or PP. We recommend discussing your specific material formula with our engineers during the configuration phase to ensure optimal screw design and processing parameters.
Q5: What is the typical production output (meters per hour) for a standard double-wall pipe?
A: Output is highly dependent on pipe diameter, wall thickness, and material. For example, a machine producing 315mm double-wall HDPE pipe might achieve an output in the range of 150-250 meters per hour. We will provide projected output figures based on your target product specifications.
Q6: Does the machine come as a complete production line?
A: Yes, we typically offer a complete turnkey solution. This includes the extruder, servo-driven structured wall pipe head, customizable profile molds, vacuum calibration system, multi-stage cooling tank, haul-off unit, cutting device, and the central control cabinet. Ancillary equipment like material loaders and dryers can also be supplied.
Q7: What are the power requirements for operating this machine?
A: Power requirements vary with the machine size and configuration. A standard line may require a 3-phase electrical supply in the range of 100-300 kW. We will provide detailed technical specifications and facility layout requirements during the project planning stage.
Q8: How does your company ensure consistent manufacturing quality?
A> Our manufacturing processes are governed by our ISO9001 quality management system. We use quality-controlled materials, advanced CNC machining for critical components, and implement strict quality checks at every assembly stage. Each machine undergoes a comprehensive factory acceptance test before shipment.
