As a specialized manufacturer in high-performance engineering plastics, Shanghai Wenqin Plastics Co., Ltd. is proud to present our premium Glass Filled PA66 Pellets, grade 13G30BK. Engineered with 30% glass fiber reinforcement, this material is designed to deliver exceptional mechanical strength, dimensional stability, and heat resistance, making it a reliable solution for demanding industrial applications. Our commitment to quality management, evidenced by certifications like ISO9001, ensures that every batch meets stringent performance standards, providing our global clients in North America, Europe, and Asia with a consistent and trustworthy material source.
This grade is specifically formulated to overcome the limitations of unreinforced nylons. The incorporation of 30% glass fiber significantly enhances the base PA66 polymer, resulting in a composite material that excels in challenging environments. Key advantages include:
Superior Mechanical Properties: The glass fibers provide a substantial increase in tensile strength, flexural modulus, and impact resistance, allowing for the design of thinner, lighter, yet stronger parts.
Excellent Dimensional Stability: Reduced moisture absorption and a low coefficient of thermal expansion minimize part warpage and dimensional change, ensuring precise fit and function over a wide temperature range.
Enhanced Thermal Performance The heat deflection temperature (HDT) is markedly improved, enabling the material to perform reliably in elevated temperature applications common in under-hood automotive and electrical components.
Good Chemical Resistance: Maintains performance when exposed to many oils, greases, and fuels, which is critical for automotive and mechanical applications.
The technical specifications of our 13G30BK pellets are detailed below. These values are typical and can be verified with specific test reports.
| Property | Test Method | Typical Value | Unit |
| Density | ISO 1183 | 1.36 | g/cm³ |
| Tensile Strength | ISO 527 | 180 | MPa |
| Flexural Modulus | ISO 178 | 9500 | MPa |
| Izod Notched Impact (23°C) | ISO 180/1A | 12 | kJ/m² |
| Heat Deflection Temp (1.8MPa) | ISO 75-1/-2 | 250 | °C |
| Moisture Absorption (Saturation) | - | ~6.5 | % |
For our customers, this translates into tangible benefits. You can achieve cost-effective part production through faster cycle times and the ability to down-gauge wall thickness without sacrificing performance. The material's stability leads to higher production yields with fewer rejects due to warpage. Furthermore, it enables the replacement of more expensive materials like metals or other engineering plastics in applications requiring a balance of strength, stiffness, and thermal resistance.
Common application areas include:
Automotive: Engine covers, cooling fans, intake manifolds, structural brackets, and connectors.
Electrical & Electronics: Housings for circuit breakers, connectors, coil bobbins, and various insulating components.
Industrial & Consumer Goods: Power tool housings, gears, rollers, and functional components requiring durability.
Backed by Shanghai Wenqin Plastics' integrated quality systems including ISO9001 and ISO14000, our 13G30BK PA66 pellets are produced with consistent quality control from raw material to finished pellets. Our strategic location in Shanghai and shipment ports like Shanghai and Ningbo facilitate efficient logistics to our main markets across North America, Europe, Asia, and beyond. With a dedicated team of 11-50 professionals, we focus on delivering reliable performance materials that help your products succeed. Choose our Glass Filled PA66 for a robust, high-performance material solution backed by technical support and dependable supply. Contact us today for detailed specifications, samples, or a customized quote to meet your specific project requirements.
Frequently Asked Questions (FAQ)
What is the main difference between PA66 and this glass-filled version?
Unreinforced PA66 offers good toughness and wear resistance. The 30% glass fiber reinforcement in this grade significantly increases tensile strength, stiffness (modulus), and heat resistance while reducing moisture absorption effects and thermal expansion, making it suitable for structural, load-bearing parts.Is pre-drying necessary before processing?
Yes. Like most polyamides, this material is hygroscopic. We recommend drying at 80-90°C for 3-4 hours prior to processing to achieve optimal mechanical properties and surface finish. Improper drying can lead to splay marks or reduced performance.What are the typical processing conditions for injection molding?
A melt temperature range of 280-300°C and a mold temperature of 70-100°C are common starting points. Specific settings may vary based on part design and mold geometry. Technical datasheets with detailed processing guidelines are available upon request.Can this material be colored?
The standard product is supplied in natural color. However, we offer black masterbatch (as indicated by "BK" in the grade) or can provide custom color compounding services upon request to match your specific requirements.How does it compare to PA6 with glass fiber?
PA66 generally has a higher melting point, better heat resistance, and slightly lower moisture absorption than PA6. The glass-filled versions inherit these base polymer differences. PA66 GF30 is often chosen for applications demanding higher continuous use temperatures.What packaging is used for shipment?
The pellets are typically packed in 25 kg multi-layer paper bags with polyethylene liners to ensure dryness and cleanliness during transport and storage. Other packaging options can be discussed.Do you provide material certifications or test reports?
Yes. Certificates of Analysis (CoA) with key property data are provided with each shipment. Full test reports according to international standards can be supplied upon request.Is this material suitable for food contact applications?
The standard 13G30BK grade is not specifically formulated or certified for food contact. For such applications, please inquire about our specialized food-grade compliant compounds.
