Pepperl+Fuchs HIC2025 SMART Transmitter Power Supply | |
Model Number: |
HIC2025 |
Condition: |
100% Original New |
Warranty: |
12 Months |
Package: |
Standard Packing |
Payment Method: |
Wire Transfer |
Shipping Method: |
DHLUPSFedexEMSOthers |
Contact us to Get Best Price!
Your Other Options | |
|
330500-02-04 330500-02-04 6SX7010-0FF05 DI818 3BSE069052R1 DO818 3BSE069053R1 DO818 3BSE069053R1
|
330103-02-12-05-02-05 330103-00-15-10-02-00 330909-00-60-10-01-CN 330909-00-80-10-01-00 3500/15 106M1079-01 TK-3E 177313-02-02-00 CI867AK01 3BSE092689R1
|
Specifications or Description
Functional safety parameters: SIL 2, SC 3.
Power supply via termination board: 19–30 V DC, ripple ≤ 10 %; rated current ≤ 45 mA at 24 V with 20 mA source output; power dissipation ≤ 800 mW, consumption ≤ 1.1 W.
Supply connections: SL1 1a/1b negative, 2a/2b positive.
Input on field side: 4–20 mA limited to ≈ 26 mA; connections SL2 5a positive, 1b or 5b negative; voltage drop ≈ 5 V on 5a/1b pair; available ≥ 15 V at 20 mA, ≥ 18 V at 4 mA on 5a/5b pair.
Output on control side: source mode 4–20 mA or 1–5 V (internal 250 Ω, 0.1 %) across 0–350 Ω load; sink mode 4–20 mA at 10–30 V operating; extra loads add voltage drop (e.g. 250 Ω × 20 mA = 5 V); ripple 20 mV rms.
