Here is a brief description for the WMM Series 4WMM6 Directional Spool Valves, Direct Operated with Mechanical or Manual Actuation:
The WMM Series 4WMM6 directional spool valves are direct-operated, mechanically or manually actuated valves designed for controlling the start, stop, and direction of fluid flow in hydraulic systems. These valves are engineered for reliability and versatility in various industrial applications.
🔑 Key Features:High Performance: Operates at pressures up to 315 bar and flow rates up to 60 L/min, making it suitable for medium-flow hydraulic systems.
Flexible Configurations: Available in two- or three-position variants with two-, three-, or four-way options (e.g., 3/2, 3/3, 4/2, 4/3), allowing for customized flow control.
Robust Construction: Designed with a durable housing, hardened control spool, and reset springs, ensuring longevity and consistent performance even in demanding environments.
Manual Actuation: Features a handle-based mechanical operation for precise control, with options for position detents or spring return to maintain or automatically reset the spool position.
Universal Installation: Can be mounted in any orientation and complies with standard porting patterns (DIN 24340 Form A and ISO 4401-03-02-0-05), simplifying integration into existing systems.
Environmental Resilience: Functions effectively across a wide temperature range (-20°C to +80°C) and viscosity range (2.8 to 500 mm²/s), ensuring reliability in diverse operating conditions.
Optional Accessories: Supports the use of throttling plugs (to prevent flow overrun during switching) and position sensing switches (for non-contact feedback), enhancing functionality and safety.
Ideal for use in:
Industrial machinery (e.g., machine tools, presses)
Mobile equipment
Automation systems requiring manual directional control
Direct operation ensures simple, responsive control without the need for pilot pressure.
Detent options provide stable position locking for reliable operation.
Compact and lightweight design (approx. 1.4 kg) saves space and simplifies handling.
This valve series is widely used in industries requiring robust and flexible hydraulic direction control, offering efficient performance and ease of use.
