Help CenterMO Titanium Electrolytic Cell for Hypochlorous Acid Generator - 3 Ru-Ir Anodes
Related Products
-
1pc MMO Titanium Anode & 2pcs Titanium Cathodes Electrode Mesh With Ru-Ir CoatingUS$ 53.91 - 59.99MOQ: 1 Combo -
MMO Titanium Anode Electrode With Iridium Tantalum Coating – 100 * 50mm for Electrolysis, Electroplating, Water TreatmentUS$ 31.49 - 34.99MOQ: 1 Combo
-
TIBROMTACK Titanium Cup With Lid 450ml Camping Cup Coffee MugUS$ 17.99 - 19.99MOQ: 1 Combo
-
TIBROMTACK for Tesla Model-S（2014-2019） Carbon Fibre Car Door Threshold Protection StickerUS$ 71.82 - 79.8MOQ: 1 Combo
-
for Tesla Model-s/x Accessories 2014-2019 Carbon Fibre Steering Wheel StickerUS$ 9.54 - 10.6MOQ: 1 Combo
Instructions:
1、 The tankis installed vertically, with a single water nozzle as the inlet (located atthe bottom during installation) and dual water nozzles as the acid and alkalineoutlets (located at the top during installation).
2、 When theelectrolytic cell is activated, water should be supplied first and thenelectricity should be supplied. When it is turned off, power should bedisconnected first and then water should be cut off.
3、 The waterquality treated by the electrolytic cell must be filtered clean tap water orpurified water
4、 When thewater pressure is less than 0.1Mpa, the outlet must not be closed during use,otherwise the electrolytic cell will be damaged.
5、 The twosides of the electrolytic cell are wiring terminals, each connected to positiveand negative poles, and the current must be a DC power supply. Adjust thecurrent size according to the pH requirements (depending on the water quality,the current size may vary, and it is necessary to start with a small currentexperiment. It is recommended to start with a current of 0.3A)
6、 It can bereversed to reduce scaling inside the tank.
7、 Noncollidable, used at room temperature
Technical indicators:
1、 Thevoltage used is 0-24V, the current is 0A-5A (adjustable from small to large),the normal electrolysis standard range is pH 5.0-9 (inlet water 3-5 ‰ sodiumchloride solution), and the high electrolysis range is pH 3.5-10.5 (consulttechnical service personnel).
2、 Thesingle water nozzle of the electrolytic cell has a 2-minute (replaceable by 3minutes) inlet, and the double water nozzle has a 2-minute (replaceable by 3minutes) outlet. The acid-base outlet ratio is 1:1 (adjustable), and themaximum inlet water volume is 80L/hour.
3、 Main bodysize specification: 220 * 110 * 30MM (excluding terminal posts and wateroutlet).
· �� Pro-Grade MMO Coating Durability 3-plates Ru-Ir coated titanium anodes withstand 24V/5A continuous operation, Normal electrolysis standard range PH: 5-9 environments for 10000+ hour lifespan.
· �� Precision Flow Control System Dual-outlet design with 80L/h max flow rate, for 3-5‰ NaCl solutions (requires filtered water pressure
· ⚙️ Installation Ready Pre-installed vertical mounting brackets + 3 free water connectors. One inlet is below and two outlets are above. It can be reversed to reduce scaling inside the tank.
· �� Fail-Safe Operation Protocol Auto-protection design: Must start with water flow → power ON (initial 0.3A), shutdown sequence: Power OFF → water OFF. CE-certified ABS housing prevents dry burn.
· �� Industrial Compact Design 220×110×30mm body fits tight spaces (excl. ports). The current must be a direct current DC power source. Adjust the current according to the required pH level for use.
