| Product Name: | Nickel Alloy Seamless Tube | Material Grade: | Incoloy 800(1.4876), Incoloy 800H(1.4958),800HT(1.4959), 825(2.4858). Inconel 600(2.4816), 601(2.4851), 625(2.4856),690(2.4642), 718(2.4668). Monel 400(2.4360/2.4361) |
|---|---|---|---|
| Type: | Cold Drawn Seamless / Welded / ERW | End: | Plain Ends / Beveled Ends |
| Delivery Conditions: | As Rolled, Cold Drawn, Hot Finish, Stress Relieved, Annealed, Hardened, Tempered | Coating: | Electropolish, Mechanical Polish, Satin Finish, Passivated |
| Packaging: | Loose / Bundle / Wooden Pallet / Wooden Box-a / Plastic Cloth Wraps / Plastic End Caps / Beveled Protector | Testing: | NACE MRO175, Hardness Test, Flare, Hydrostatic Test, Eddy Current Test, Grain Size Test, Eddy Current, Annealed, Tempered, Stress Relieved Etc. |
| High Light: | Nickel Alloy Seamless Heat Exchanger Tube, 800 Nickel Alloy Seamless Tube, UNS N08810 Heat Exchanger Tube | ||
ASTM B407 ASME SB407 UNS N08810 Alloy 800 NICKEL ALLOY SEAMLESS TUBE ABS APPROVED
Incoloy 800H is primarily used in applications where temperatures do not exceed 1100° F, while alloys 800H and 800HT are typically used in temperatures above 1100° F where creep and fracture resistance is required. The chemical balance gives the nickel-steel alloys excellent resistance to carburising, oxidising and nitriding atmospheres, and Incoloy 800HT will not become embrittled even after prolonged use in the 1200-1600°F temperature range, where many stainless steels become brittle. The excellent cold forming properties normally associated with nickel-chromium alloys are also evident in 800HT. During cold forming, grain size produces a distinctly undulating surface known as "orange peel" Incoloy 800HT can be welded by techniques commonly used for stainless steels.
Chemical Composition
| Alloy | % | Ni | Cr | Fe | C | Mn | Si | Cu | S | Al | Ti |
| UNS N08800 | Min. | 30 | 19 | 0.15 | 0.15 | ||||||
| - | Max. | 35 | 23 | balance | 0.1 | 1.5 | 1 | 0.75 | 0.015 | 0.6 | 0.6 |
| UNS N08810 | Min. | 30 | 19 | 0.05 | 0.15 | 0.15 | |||||
| - | Max. | 35 | 23 | balance | 0.1 | 1.5 | 1 | 0.75 | 0.015 | 0.6 | 0.6 |
| UNS N08811 | Min. | 30 | 19 | 0.06 | 0.15 | 0.15 | |||||
| - | Max. | 35 | 23 | balance | 0.1 | 1.5 | 1 | 0.75 | 0.015 | 0.6 | 0.6 |
Mechanical Properties
The mechanical properties of Incoloy 800/800HT combined with their corrosion resistance at elevated temperatures make Incoloy alloys extremely versatile in a variety of high temperature and long term operations. These alloys are also used in a wide variety of applications in corrosive media.The chemical composition of Incoloy 800H and 800HT is limited to that of INCOLOY Alloy 800. Alloy 800 has high mechanical strength at elevated temperatures. The important difference between the Incoloy alloy families is the difference in mechanical properties. The differences in mechanical properties are due to differences in chemical composition and annealing temperatures. In general, Incoloy 800 alloys have high mechanical properties at room temperature and the lowest mechanical properties at elevated temperatures. On the other hand, Incoloy 800H and 800HT alloys have higher creep and stress fracture strengths at higher temperatures.
Specifications
Rod, Bar, Wire, Forgings and Forging Stock | ASTM B 408, ASME SB 408 (Rod & Bar), ASTM B 564, ASME SB 564 (Forgings), ASME Code Case 1325 (All Product Forms), ASME Code Case 1949 (Forgings), AMS 5766 (Rod & Bar), ISO 9723 (Rod & Bar), ISO 9724 (Wire), ISO 9725 (Forgings), BS 3076NA15 (Rod & Bar), BS 3075NA15 (Wire), VdTÜV 412 (All Products). |
| Plate, Sheet, and Strip | ASTM A 240, ASTM A 480, ASME SA 240, ASME SA 480 (Plate, Sheet, and Strip), ASTM B 409, ASTM B 906, ASME SB 409, ASME SB 906 (Plate, Sheet, and Strip), ASME Code Case 1325 (All Product Forms), ASME Code Case 2339 (Plate), AMS 5871 (Plate, Sheet, and Strip), BS3072NA15 (Plate & Sheet), BS 3073NA15 (Strip), VdTÜV 412 (All Products), ISO 6208 (plate, sheet andstrip). |
| Pipe and Tubes | ASTM B 163 & ASME SB 163 (Seamless Condenser & Heat Exchanger Tubes), ASTM B407, ASTM B 829, ASME SB 407, ASME SB 829 (Seamless Pipe & Tubes), ASTM B 514, ASTM B 775, ASME SB 514, ASME SB 775 (Welded Pipe), ASTM B 515, ASTM B 751, ASME SB 515, ASME SB 751(Welded Tubes), ASME Code Case 1325 (All Product Forms), ASME N-20 (Cold Worked Seamless Condenser and Heat Exchanger Tubes for Nuclear Service), BS 3074NA15 (Seamless Pipe & Tubes), VdTÜV 412 (All Products), ISO 6207 (Seamless Tubing). |
APPLICAITONS
Sulphuric acid piping and vessels
Phosphoric acid evaporators
Pickling tank heaters, pickling tanks and equipment
Chemical process equipment
Propellor shafts
Tank trucks
Calorifiers
Electrostatic precipitator electrodes
Hot vessels for food, water and seawater,
ammonium sulphate vessels
Expansion bellows
Marine exhaust systems
Power station ash hoppers
Ethylene furnace quench boilersHydrocarbon cracking Valves, fittings and other components exposed to corrosive attack from 1100-1800° F
Industrial furnaces
Heat-treating equipment
Chemical and petrochemical processing
Super-heater and re-heaters in power plants
Pressure vessels
Heat exchanger
ZHEJIANG ZHONGZHENG STAINLESS STEE MANUFACTURING CO. LTD. is a professional supplier of stainless steel materials, located in Zhejiang, China with high speed of economic development. We are near shanghai port; the traffic is very convenient.The main stainless steel materials are stainless steel plate, pressure vessel stainless steel plate, high temperature boiler plate, corrosion resistant stainless steel plate, stainless steel seamless pipe, stainless steel industrial pipe, stainless steel welded pipe, stainless steel bar, stainless steel pipe and so on.With the aim of "quality first, timely delivery, good faith cooperation, considerate service and common development", the company has set up a good reputation in the industry for providing high quality stainless steel materials and perfect after-sales service.
1. Exceptional Service: We guarantee a response to all inquiries within 12 hours.
2. Certifications: Proudly holding ISO 9001, CE, and SGS certifications.
3. Cost - Effective Quality: Benefit from competitive prices and top - notch quality, as our products are directly sourced from our own factory.
4. Robust Production Capacity: With a monthly output of 20,000 tons, we ensure seamless production.
5. Flexible Payment Terms: We accept various payment methods, including T/T and L/C.
6. Swift Delivery & Standard Export Packaging: Expect quick delivery and products packaged in line with international export standards.
7. Factory - Direct Advantage: Our own factory enables us to offer competitive prices without compromising on quality.
8. Third - Party Testing: We welcome any third - party testing to verify the quality of our products.
9. Expert Team Support: Backed by a professional sales team and a reliable factory.
10.Dedicated to Customization: Your individual specifications are not just accepted-they're the cornerstone of our service. We're committed to delivering on every customized request.
