30 cm Plate Load Test Device 10 kg Falling Weight Deflectometer Dynamic Modulus of Deformation Test
- 0 Set / Sets per Month
- qingdao,shanghai, tianjin
- T/T L/C PayPal D/P Western Union Other
- 7 days
You May Like
-
Non-Destructive Soil Compaction Tester Railway Track Subgrade Testing Equipment Road Construction Quality Control Tester
-
Pavement Layer Modulus Measurement Earthwork Compaction Verification Tool Airfield Runway Soil Testing Device
-
Best Evd Tester Price Portable Dynamic Deformation Modulus Tester Evd Tester Supplier/Manufacturer
-
High-Precision Evd Testing Equipment Chinese Evd Testing Equipment Suppliers Static Plate Load Test (Ev2) Equipment
-
Portable Falling Weight Deflectometer (PFWD) Soil Bearing Capacity Test Machine Geotechnical Field Testing Instruments
-
Soil Compaction Testing Devices
Product Details
Test range | 10Mpa≤Evd≤225Mpa | Test depth | 0~500mm | |
Loading device | 15kg | drop weight | 10kg | |
Maximum impact | 7.07kN | Impact duration | 18±1ms | |
Load plate diameter | 300mm | load plate thickness | 20mm | |
Submergence test range | 0.10mm~2.00mm | Storage capacity | 2000 sets of test data | |
Origin | China |
Product Description
GTJ-Evd Dynamic Deformation Modulus Tester (Handheld Drop Weight Deflectometer)
Usage overview
The GTJ-Evd type dynamic deformation modulus tester (hand-held drop weight deflection instrument) is used to determine the deflection capacity of the subgrade under the dynamic load, thereby evaluating the bearing capacity and deformation of the subgrade. It is applicable to the monitoring and inspection of foundation construction quality of railways, highways, airports, urban traffic, ports, terminals and industrial and civil buildings subjected to dynamic loads. It is especially suitable for the detection of narrow sections of the site, such as the transition of roads and bridges (culverts) and the detection of shoulders. , both line base and so on. It can quickly measure the dynamic deformation modulus Evd value.
Applicable standard
"Earth Test Method for Railway Engineering" (TB10102-2010) "Evd Plate Load Test".
Features
※ Imported sensors and some components are used for high test accuracy.
※ LCD display in English and Chinese, there are corresponding Chinese and English prompts under different interfaces; with backlight, it has better visibility in various environments.
※ The operation is simple, the test speed is fast, and the detection takes only 35 seconds.
※ The Evd value is automatically calculated and the curve is displayed, which is accurate and intuitive.
※ Handheld main unit with Bluetooth micro-printer, direct printing on site to ensure accurate and objective test results.
※ USB transmission interface, easy to connect with the computer.
※ This instrument simulates the impact of the train on the subgrade when driving at high speed. Compared with the static load test, it can reflect the actual stress of the subgrade soil.
※ Non-nuclear radiation and exhaust gas pollution, safe and environmentally friendly.
Technical Parameters
Scope of application | Applicable soil type | Various types of soil and earth and rock mixed fillers with a particle size not larger than 1/4 of the diameter of the load plate |
Test range | 10Mpa≤Evd≤225Mpa | |
Test depth | 0~500mm | |
Working environment | Temperature -10°C~40°C Humidity<90%HR | |
Data acquisition device | Loading device | Weight: 15kg, including drop weight: 10kg Maximum impact: 7.07kN Impact duration: 18±1ms |
Load plate | Weight: 15kg Diameter: 300mm Thickness: 20mm | |
Handheld host | Submergence test range | 0.10mm~2.00mm |
Storage capacity | 2000 sets of test data | |
Specifications | Screen size: 3 inches Volume: 100 × 205 × 40mm Weight: 0.8kg | |
Power supply mode | Large capacity lithium battery, working time is more than 18 hours | |
Display mode | Chinese and English switching display | |
Printer | connection method | wireless bluetooth printing |
Packing Specifications | Main Chassis | Material: Engineering Plastics Volume: 420 × 140 × 335mm Weight: 4.5kg |
Outer box | Material: Aluminum alloy Volume: 1220 × 395 × 380mm Weight: 56kg |
Instrument composition
