Ventura 20FP22H1CT-R Nickel cadmium batteries for aviation use CHINA F20/22H1C-1

Ventura FP22H1C P/N F20/22H1C-1 Nickel ca

dmium batteries for aviation use

Ventura FP22H1C P/N F20/22H1C-1

F20/22H1C-1 (China)

20FP22H1CT-R (Russia)

Ventura nickel cadmium aviation battery

Ventura nickel cadmium batteries typically consist of 20 individual cells, which are installed inside a stainless steel box lined with heat-resistant plastic. The battery cover and high conductivity nickel plated copper core are supported and protected by soft rubber. The pipeline installed on the side of the battery is used for exhaust, and the plug installed on the front of the battery is used to connect the battery to the aircraft's electrical system. In addition, the battery can be equipped with a temperature sensor for temperature monitoring.

 Ventura FP22H1C P/N F20/22H1C-1

Low internal resistance can still provide excellent power output at extreme temperatures.

Specially designed isolation materials can maintain stability even at high temperatures, ensuring high safety without any "heat dissipation".

Unique individual design achieves ultra-low self discharge level

Long service life and storage life

F20/22H1C-1 (China)

20FP22H1CT-R (Russia)

Ventura ® Nickel Cadmium Aviation

 Ventura FP22H1C P/N F20/22H1C-1

Technology/Chemistry: Nickel cadmium batteries

Application areas: Military aircraft: Commercial aircraft

Capacity (minimum) - European standard: 7

Capacity (maximum) - European standard: 44

European standard capacity: C1 @ 20 Deg C

Voltage (minimum value): 24

Voltage (maximum): 24

Ventura FP22H1C P/N F20/22H1C-1

Battery type: FP3.3H1C FP12H1C、FP22H1C、FP17H1C、FP15H1C、FP7H1C、FP27H1C、FP25H1C、FP40H1C

Title: Nickel cadmium battery, aviation battery, aviation power supply, ground power system
