Product Details
Type | Seamless | Surface Treatment | Polished | |
Usage | Pipeline Transport, Boiler Pipe, Oil/Gas Drilling, Machinery Industry, Chemical Industry, Mining, Special Purpose | Material | Alloy Steel | |
Section Shape | Round | Delivery Time | 8-14 days | |
Model Number | 304 316 310 904 2205 2507 | Processing Service | Bending, Welding, Decoiling, Punching, C | |
Specification | 0D 3in under |
Product Description
Standard | ASTM A213/A312/A376/A279 /A789/A790/A450/A999ETC |
Grade | TP 304,TP304L,TP316/316L/316TI |
TP 309S,310S | |
TP 347/347H,TP321/321H | |
TP904L | |
S31803,S32205,S32304,S32750 | |
SAF2205,SAF2304,SAF2507 | |
MOQ | 1 PCS |
Manfacturing Method | Cold Drawing/Welding/Cold rolled |
Outside Diameter Range | 6mm-508mm |
Wall Thickness Range | 1mm-40mm |
Length Range | 1M-12M |
Pipe end | BE/PE |
Chemical Composition and Mechanical Property | ||||||||||||||
Chemical components | Mechanical Property | |||||||||||||
Grade | C | Mn | P | S | Si | Cr | Ni | Yield | Tensile | Elongation | ||||
Strength | strength | |||||||||||||
(MPa) | (MPa) | % | ||||||||||||
Max. | Max. | Max. | Max. | Max. | Min. | Max. | Min. | Max. | Max. | Min. | Max. | Min. | Min | |
TP 304 | 0.08 | 2.00 | 0.05 | 0.03 | 1.00 | 18.00 | 20.00 | 8.00 | 11.0. | 540 | 515 | 240 | 205 | 35 |
TP 304L | 0.04 | 2.00 | 0.05 | 0.03 | 1.00 | 18.00 | 20.00 | 8.00 | 12.00 | 485 | 170 | 35 | ||
TP 309S | 0.08 | 2.00 | 0.05 | 0.03 | 1.00 | 22.00 | 24.00 | 12.00 | 15.00 | 600 | 515 | 310 | 205 | 35 |
TP 310S | 0.08 | 2.00 | 0.05 | 0.03 | 1.00 | 24.00 | 26.00 | 19.00 | 22.00 | 515 | 205 | 35 | ||
TP 316 | 0.08 | 2.00 | 0.05 | 0.03 | 1.00 | 16.00 | 18.00 | 10.00 | 14.00 | 515 | 450 | 205 | 200 | 35 |
TP 316L | 0.04 | 2.00 | 0.05 | 0.03 | 1.00 | 16.00 | 18.00 | 10.00 | 14.00 | 485 | 170 | 35 |
Dimension Tolerance
Permitted Variations in Wall Thickness | ||||||||
Wall Thickness % | ||||||||
Outside Diameter in. (mm) | 0.095(2.4) and under | Over 0.095 to 0.150 (2.4 to 3.8) incl | Over 0.150 to 0.0180 (3.8 to 4.6) incl | Over 0.180 (4.6) | ||||
Over | Under | Over | Under | Over | Under | Over | Under | |
Seamless, Hot-Finished Tubes | ||||||||
4(100)and under | 40 | 0 | 35 | 0 | 33 | 0 | 28 | 0 |
Over 4(100) | 35 | 0 | 33 | 0 | 28 | 0 | ||
Seamless, Cold-Finished Tubes | ||||||||
Over | Under | |||||||
1½ (38.1) and under | 20 | 0 | ||||||
Over 1½ (38.1) | 22 | 0 | ||||||
Welded Tubes | ||||||||
All sizes | 18 | 0 |
Permitted Variations in Outside Diameter | ||
Specified Outside Diameter | Permitted Variations in (mm) | |
in(mm) | Over | Under |
Hot-Finished Seamless Tubes | ||
4(100) or under | 1/64 (0.4) | 1/32 (0.8) |
Over 4 to 7 ½ (100 to 200) incl | 1/64 (0.4) | 3/64 (1.2) |
Over 7 ½ to 9 (200 to 225) incl | 1/64 (0.4) | 1/16 (1.6) |
Welded Tubes and Cold-Finished Seamless Tubes | ||
Under 1(25) | 0.004 (0.1) | 0.004 (0.1) |
1 to 1½ (25 to 40) incl | 0.006 (0.15) | 0.006 (0.15) |
Over 1½ to 2 (40 to 50) excl | 0.008 (0.2) | 0.008 (0.2) |
2 to 2½ (50 to 65) excl | 0.010 (0.25) | 0.010 (0.25) |
2½ to 3 (65 to 75) excl | 0.012 (0.3) | 0.012 (0.3) |
3 to 4 (75 to 100) incl | 0.015 (0.38) | 0.015 (0.38) |
Over 4 to 7 ½ (100 to 200) incl | 0.015 (0.38) | 0.025 (0.64) |
Over 7 ½ to 9 (200 to 225) incl | 0.015 (0.38) | 0..045 (1.14) |
ASTM A358 / ASME SA358 Stainless Steel EFW Pipes
Standard Specification for Electric-Fusion-Welded Austenitic Chromium-Nickel Stainless Steel Pipe for High-Temperature Service and General Applications
ASTM A358 Stainless Steel EFW Pipes specification covers electric-fusion-welded austenitic chromium-nickel stainless steel pipe suitable for corrosive or high-temperature service, or both, or for general applications.
The dimensionless designator NPS (nominal pipe size) has been substituted in this standard for such traditional terms as "nominal diameter," "size," and "nominal size."
This specification covers the grades of alloy and stainless steel listed in Table 1. The selection of the proper grade and requirements for heat treatment shall be at the discretion of the purchaser, dependent on the service conditions to be encountered.
Five classes of pipe are covered as follows:
ASTM A358 Class 1 - Pipe shall be double welded by processes employing filler metal in all passes and shall be completely radiographed.
ASTM A358 Class 2 - Pipe shall be double welded by processes employing filler metal in all passes. No radiography is required.
ASTM A358 Class 3 - Pipe shall be single welded by processes employing filler metal in all passes and shall be completely radiographed.
ASTM A358 Class 4 - Same as Class 3 except that the weld pass exposed to the inside pipe surface may be made without the addition of filler metal (see 6.2.2.1 and 6.2.2.2).
ASTM A358 Class 5 - Pipe shall be double welded by processes employing filler metal in all passes and shall be spot radiographed.
Supplementary requirements covering provisions ranging from additional testing to formalized procedures for manufacturing practice are provided. Supplementary Requirements S1 through S6 are included as options to be specified when desired.
The values stated in either inch-pound units or SI units are to be regarded separately as standard. Within the text, the SI units are shown in brackets. The values stated in each system may not be exact equivalents; therefore, each system shall be used independently of the other. Combining values from the two systems may result in nonconformance with the specification. The inch-pound units shall apply unless the "M" designation of this specification is specified in the order.
304H stainless steel (UNS S30409) Grade 304 is the standard "18/8" stainless" it is the most versatile and most widely used stainless steel, available in a wider range of products, forms and finishes than any other. It has excellent forming and welding characteristics. The balanced austenitic structure of Grade 304 enables it to be severely deep drawn without intermediate annealing, which has made this grade dominant in the manufacture of drawn stainless parts such as sinks, hollow-ware and saucepans. for these applications it is common to use special "304DDQ" (Deep Drawing Quality) variants. Grade 304 is readily brake or roll formed into a variety of components for applications in the industrial, architectural, and transportation fields. Grade 304 also has outstanding welding characteristics. Post-weld annealing is not required when welding thin sections.
Grade 304L, the low carbon version of 304, does not require post-weld annealing and so is extensively used in heavy gauge components (over about 6mm). Grade 304H with its higher carbon content finds application at elevated temperatures. The austenitic structure also gives these grades excellent toughness, even down to cryogenic temperatures
duct Show
304 stainless steel pipe
Parameter class | Parameter name | Parameter value |
Material | Brand | 304 |
Chemical composition | C≤0.08%, Cr 18%-20%, Ni 8%-10.5% | |
specification | Outside diameter | 10mm-500mm |
Wall thickness | 0.5mm-20mm | |
Surface state | Surface treatment | 2B BA NO.4 |
Mechanical property | Tensile strength | ≥515 MPa |
Yield strength | ≥205 MPa | |
Rate of elongation | ≥40% | |
Standard | Production standard | GB/T 12771 ASTM A312 |
316L stainless steel pipe
Parameter class | Parameter name | Parameter value |
Material | Brand | 316l |
Chemical composition | C≤0.03%, Cr 16%-18%, Ni 10%-14% Mo 2%-3% | |
specification | Outside diameter | 10mm-500mm |
Wall thickness | 0.5mm-20mm | |
Surface state | Surface treatment | 2B BA NO.4 |
Mechanical property | Tensile strength | ≥485 MPa |
Yield strength | ≥170 MPa | |
Rate of elongation | ≥40% | |
Standard | Production standard | GB/T 12771 ASTM A312 |
Parameter class | Parameter name | Parameter value |
Material | Brand | 2205 |
Chemical composition | C≤0.03%, Cr 22%-23%, Ni 4.5%-6.5% Mo 3%-3.5% N 0.14%-0.2% | |
specification | Outside diameter | 10mm-500mm |
Wall thickness | 0.5mm-20mm | |
Surface state | Surface treatment | 2B BA NO.4 |
Mechanical property | Tensile strength | ≥620 MPa |
Yield strength | ≥450 MPa | |
Rate of elongation | ≥25% | |
Standard | Production standard | ASTMA790 EN10216-5 |
Chemical Composition (%) | Mechanical Performance | ||||||||||||||
Grade | C | Mn | P | S | Si | Cr | Ni | Mo | N | Ti | Others | Mpa (kgf/mm²) | Elongation .(%) em 2" (min.) | Hardness | |
(AISI) | (max.) | (max.) | (max) | (max.) | (max.) | (min.) | (min.) | (min.) | (min.) | (min.) | HRB | ||||
(max.) | (max.) | (max.) | (max.) | (max.) | Tensile strength (min.) | Yield strength (min.) | (max.) | ||||||||
304 | 0,080 | 2,0 | 0,045 | 0,030 | 1,00 | 18,0 | 8,0 | 515 | 205 | 35 | 90 | ||||
20,0 | 11,0 | ||||||||||||||
304L | 0,035 | 2,00 | 0,045 | 0,030 | 1,00 | 18,0 | 8,0 | 485 | 170 | 35 | 90 | ||||
20,0 | 13,0 | ||||||||||||||
304H | 0,040 | 2,00 | 0,045 | 0,030 | 1,00 | 18,0 | 8,0 | 515 | 205 | 35 | 90 | ||||
0,100 | 20,0 | 11,0 | |||||||||||||
309S | 0,080 | 2,00 | 0,045 | 0,030 | 1,00 | 22,0 | 12,0 | 0,75 | 515 | 205 | 35 | 90 | |||
24,0 | 15,0 | ||||||||||||||
310 | 0,150 | 2,00 | 0,045 | 0,030 | 1,00 | 24,0 | 19,0 | 515 | 205 | 35 | 90 | ||||
26,0 | 22,0 | ||||||||||||||
310S | 0,080 | 2,00 | 0,045 | 0,030 | 1,00 | 24,0 | 19,0 | 0,75 | 515 | 205 | 35 | 90 | |||
26,0 | 22,0 | ||||||||||||||
310H | 0,040 | 2,00 | 0,045 | 0,030 | 1,00 | 24,0 | 19,0 | 515 | 205 | 35 | 90 | ||||
0,100 | 26,0 | 22,0 | |||||||||||||
314 | 0,200 | 2,00 | 0,045 | 0,015 | 1,50 | 24,0 | 19,0 | 0,11 | 515 | 205 | 35 | 90 | |||
2,50 | 26,0 | 22,0 | |||||||||||||
316 | 0,080 | 2,00 | 0,045 | 0,030 | 1,00 | 16,0 | 11,0 | 2,00 | 515 | 205 | 35 | 90 | |||
18,0 | 14,0 | 3,00 | |||||||||||||
316H | 0,040 | 2,00 | 0,045 | 0,030 | 1,00 | 16,0 | 11,0 | 2,00 | 515 | 205 | 35 | 90 | |||
0,100 | 18,0 | 14,0 | 3,00 | ||||||||||||
316L | 0,035 | 2,00 | 0,045 | 0,030 | 1,00 | 16,0 | 10,0 | 2,00 | 485 | 170 | 35 | 90 | |||
18,0 | 14,0 | 3,00 | |||||||||||||
316Ti | 0,080 | 2,00 | 0,045 | 0,030 | 0,75 | 16,0 | 10,0 | 2,00 | 0,10 max | 5x(C+N)-0,70 | 515 | 205 | 35 | 90 | |
18,0 | 14,0 | 3,00 | |||||||||||||
317L | 0,035 | 2,00 | 0,045 | 0,030 | 1,00 | 18,0 | 11,0 | 3,00 | 515 | 205 | 35 | 90 | |||
20,0 | 15,0 | 4,00 | |||||||||||||
321 | 0,080 | 2,00 | 0,045 | 0,030 | 1,00 | 17,0 | 9,0 | 0,10 max | 5x(C+N)-0,70 | 515 | 205 | 35 | 90 | ||
19,0 | 12,0 | ||||||||||||||
321H | 0,040 | 2,00 | 0,045 | 0,030 | 1,00 | 17,0 | 9,0 | 0,10 max | 4x(C+N)-0,70 | 515 | 205 | 30 | 90 | ||
0,100 | 19,0 | 12,0 | |||||||||||||
347 | 0,080 | 2,00 | 0,045 | 0,030 | 1,00 | 17,0 | 9,0 | Nb:10xC-1,00 | 515 | 205 | 35 | 90 | |||
19,0 | 13,0 | ||||||||||||||
347H | 0,040 | 2,00 | 0,045 | 0,030 | 1,00 | 17,0 | 9,0 | Nb:8xC-1,00 | 515 | 205 | 35 | 90 | |||
0,100 | 19,0 | 13,0 | |||||||||||||
S31254 254SMO | 0,020 | 1,00 | 0,030 | 0,030 | 0,08 | 19,50 | 17,50 | 6,00 | 0,18 | Cu:0,50-1,00 | t≤5mm 675 | t≤5mm 315 | 35 | 90 | |
20,50 | 18,50 | 6,50 | 0,25 | t>5mm 310 | |||||||||||
904L | 0,020 | 2,00 | 0,040 | 0,030 | 1,00 | 19,00 | 23,00 | 4,00 | 0,10 max | Cu:1,00-2,00 | 490 | 215 | 90 | ||
UNS 8904 | 23,00 | 28,00 | 5,00 | ||||||||||||
UNS31803 | 0,030 | 2,00 | 0,030 | 0,020 | 1,00 | 21,00 | 4,50 | 2,50 | 0,080 | 620 | 450 | 25 | HRC 30 | ||
23,00 | 6,50 | 3,50 | 0,20 | ||||||||||||
UNS32205 | 0,030 | 2,00 | 0,030 | 0,020 | 1,00 | 22,00 | 4,50 | 3,00 | 0,14 | 655 | 485 | 25 | HRC 30 | ||
23,00 | 6,50 | 3,50 | 0,20 | ||||||||||||
SUPER DUPLEX UNS32750 | 0,030 | 1,20 | 0,035 | 0,020 | 0,80 | 24,00 | 6,00 | 3,00 | 0,24 | Cu: 0,50 max | 800 | 550 | 15 | HRC 34 | |
26,00 | 8,00 | 5,00 | 0,32 | ||||||||||||
SUPER DUPLEX UNS32760 | 0,030 | 1,00 | 0,030 | 0,010 | 1,000 | 24,00 | 6,00 | 3,00 | 0,20 | Cu:0,50-1,00 | 750 | 550 | 25 | HRC 32 | |
26,00 | 8,00 | 4,00 | 0,30 | W:0,50-1,00 |
ANSI/ASME B36.10M B36.19M Dimension Comparison Table For Stainless Steel Seamless Tube Pipe
Norminal Pipe Size | Outside Diameter | Wall Thicknesses Schedule ANSI/ASME B36.10M,B36.19M | ||||||||||||||||
DN(in.) | D | sch5s | sch10s | sch10 | sch20 | sch30 | sch40s | STD | sch40 | sch60 | sch80s | XS | sch80 | sch100 | sch120 | sch140 | sch160 | XXS |
1/8 | 10.3 | --- | 1.24 | --- | --- | --- | 1.73 | 1.73 | 1.73 | --- | 2.41 | 2.41 | 2.41 | --- | --- | --- | --- | --- |
1/4 | 13.7 | --- | 1.65 | --- | --- | --- | 2.24 | 2.24 | 2.24 | --- | 3.02 | 3.02 | 3.02 | --- | --- | --- | --- | --- |
3/8 | 17.1 | --- | 1.65 | --- | --- | --- | 2.31 | 2.31 | 2.31 | --- | 3.2 | 3.2 | 3.2 | --- | --- | --- | --- | --- |
1/2 | 21.3 | 1.65 | 2.11 | --- | --- | --- | 2.77 | 2.77 | 2.77 | --- | 3.73 | 3.73 | 3.73 | --- | --- | --- | 4.78 | 7.47 |
3/4 | 26.7 | 1.65 | 2.11 | --- | --- | --- | 2.87 | 2.87 | 2.87 | --- | 3.91 | 3.91 | 3.91 | --- | --- | --- | 5.56 | 7.82 |
1 | 33.4 | 1.65 | 2.77 | --- | --- | --- | 3.38 | 3.38 | 3.38 | --- | 4.55 | 4.55 | 4.55 | --- | --- | --- | 6.35 | 9.09 |
1¼ | 42.2 | 1.65 | 2.77 | --- | --- | --- | 3.56 | 3.56 | 3.56 | --- | 4.85 | 4.85 | 4.85 | --- | --- | --- | 6.35 | 9.7 |
1½ | 48.3 | 1.65 | 2.77 | --- | --- | --- | 3.68 | 3.68 | 3.68 | --- | 5.08 | 5.08 | 5.08 | --- | --- | --- | 7.14 | 10.15 |
2 | 60.3 | 1.65 | 2.77 | --- | --- | --- | 3.91 | 3.91 | 3.91 | --- | 5.54 | 5.54 | 5.54 | --- | --- | --- | 8.74 | 11.07 |
2½ | 73 | 2.11 | 3.05 | --- | --- | --- | 5.16 | 5.16 | 5.16 | --- | 7.01 | 7.01 | 7.01 | --- | --- | --- | 9.53 | 14.02 |
3 | 88.9 | 2.11 | 3.05 | --- | --- | --- | 5.49 | 5.49 | 5.49 | --- | 7.62 | 7.62 | 7.62 | --- | --- | --- | 11.13 | 15.24 |
3½ | 101.6 | 2.11 | 3.05 | --- | --- | --- | 5.74 | 5.74 | 5.74 | --- | 8.08 | 8.08 | 8.08 | --- | --- | --- | --- | --- |
4 | 114.3 | 2.11 | 3.05 | --- | --- | --- | 6.02 | 6.02 | 6.02 | --- | 8.56 | 8.56 | 8.56 | --- | 11.13 | --- | 13.49 | 17.12 |
5 | 141.3 | 2.77 | 3.4 | --- | --- | --- | 6.55 | 6.55 | 6.55 | --- | 9.53 | 9.53 | 9.53 | --- | 12.7 | --- | 15.88 | 19.05 |
6 | 168.3 | 2.77 | 3.4 | --- | --- | --- | 7.11 | 7.11 | 7.11 | --- | 10.97 | 10.97 | 10.97 | --- | 14.27 | --- | 18.26 | 21.95 |
8 | 219.1 | 2.77 | 3.76 | --- | 7.04 | 8.18 | 8.18 | 8.18 | 10.31 | 12.7 | 12.7 | 12.7 | 15.09 | 18.26 | 20.62 | 23.01 | 22.23 | |
10 | 273.1 | 3.4 | 4.19 | --- | 6.35 | 7.8 | 9.27 | 9.27 | 9.27 | 12.7 | 12.7 | 12.7 | 15.09 | 18.26 | 25.4 | 28.58 | 25.4 | |
12 | 323.9 | 3.96 | 4.57 | --- | 6.35 | 8.38 | 9.53 | 9.53 | 10.31 | 14.27 | 12.7 | 12.7 | 17.48 | 21.44 | 25.4 | 28.58 | 33.32 | 25.4 |
14 | 355.6 | 3.96 | 4.78 | 6.35 | 7.92 | 9.53 | --- | 9.53 | 11.13 | 15.09 | --- | 12.7 | 19.05 | 23.83 | 27.79 | 31.75 | 35.71 | |
16 | 406.4 | 4.19 | 4.78 | 6.35 | 7.92 | 9.53 | --- | 9.53 | 12.7 | 16.66 | --- | 12.7 | 21.44 | 26.19 | 30.96 | 36.53 | 40.49 | |
18 | 457.2 | 4.19 | 4.78 | 6.35 | 7.92 | 11.13 | --- | 9.53 | 14.27 | 19.05 | --- | 12.7 | 23.83 | 29.36 | 34.93 | 39.67 | 45.24 | |
20 | 508 | 4.78 | 5.54 | 6.35 | 9.53 | 12.7 | --- | 9.53 | 15.09 | 20.62 | --- | 12.7 | 26.19 | 32.54 | 38.1 | 44.45 | 50.01 | |
22 | 558.8 | 4.78 | 5.54 | 6.35 | 9.53 | 12.7 | --- | 9.53 | --- | 22.23 | --- | 12.7 | 28.58 | 34.93 | 41.28 | 47.63 | 53.98 | |
24 | 609.6 | 5.54 | 6.35 | 6.35 | 9.53 | 14.27 | --- | 9.53 | 17.48 | 24.61 | --- | 12.7 | 30.96 | 38.89 | 46.02 | 52.37 | 59.54 | |
26 | 660.4 | --- | --- | 7.92 | 12.7 | --- | --- | 9.53 | --- | --- | --- | 12.7 | ||||||
28 | 711.2 | --- | --- | 7.92 | 12.7 | 15.88 | --- | 9.53 | --- | --- | --- | 12.7 | ||||||
30 | 762 | 6.35 | 7.92 | 7.92 | 12.7 | 15.88 | --- | 9.53 | --- | --- | --- | 12.7 | ||||||
32 | 812.8 | --- | --- | 7.92 | 12.7 | 15.88 | 17.48 | 9.53 | 17.48 | --- | --- | 12.7 | ||||||
34 | 863.6 | --- | --- | 7.92 | 12.7 | 15.88 | 17.48 | 9.53 | 17.48 | --- | --- | 12.7 | ||||||
36 | 914.4 | --- | --- | 7.92 | 12.7 | 15.88 | 19.05 | 9.53 | 19.05 | --- | --- | 12.7 | ||||||
38 | 965.2 | --- | --- | --- | --- | --- | --- | 9.53 | --- | --- | --- | 12.7 | Note: sch5s,10s,40s,80s Used for steel pipe fittings | |||||
40 | 1016 | --- | --- | --- | --- | --- | --- | 9.53 | --- | --- | --- | 12.7 | ||||||
42 | 1066.8 | --- | --- | --- | --- | --- | --- | 9.53 | --- | --- | --- | 12.7 | ||||||
44 | 1117.6 | --- | --- | --- | --- | --- | --- | 9.53 | --- | --- | --- | 12.7 | ||||||
46 | 1168.4 | --- | --- | --- | --- | --- | --- | 9.53 | --- | --- | --- | 12.7 | ||||||
48 | 1219.2 | --- | --- | --- | --- | --- | --- | 9.53 | --- | --- | --- | 12.7 |
BWG Gauge Weight Chart for Tube Wall thickness (Heat Exchanger Tube & Condensers Tube & Boilier Tube)
Outside Diameter | BWG | ||||||||
25 | 22 | 20 | 18 | 16 | 14 | 12 | 10 | ||
Wall Thickness mm | |||||||||
0.508 | 0.71 | 0.89 | 1.24 | 1.65 | 2.11 | 2.77 | 3.40 | ||
mm | inch | Weight kg/m | |||||||
6.35 | 1/4 | 0.081 | 0.109 | 0.133 | 0.174 | 0.212 | |||
9.53 | 3/8 | 0.126 | 0.157 | 0.193 | 0.257 | 0.356 | 0.429 | ||
12.7 | 1/2 | 0.214 | 0.263 | 0.356 | 0.457 | 0.612 | 0.754 | ||
15.88 | 5/8 | 0.271 | 0.334 | 0.455 | 0.588 | 0.796 | 0.995 | ||
19.05 | 3/4 | 0.327 | 0.405 | 0.553 | 0.729 | 0.895 | 1.236 | ||
25.4 | 1 | 0.44 | 0.546 | 0.75 | 0.981 | 1.234 | 1.574 | 2.05 | |
31.75 | 1 1/4 | 0.554 | 0.688 | 0.947 | 1.244 | 1.574 | 2.014 | 2.641 | |
38.1 | 1 1/2 | 0.667 | 0.832 | 1.144 | 1.514 | 1.904 | 2.454 | 3.233 | |
44.5 | 1 3/4 | 1.342 | 1.774 | 2.244 | 2.894 | 3.5 | |||
50.8 | 2 | 1.549 | 2.034 | 2.574 | 3.334 | 4.03 | |||
63.5 | 2 1/2 | 1.949 | 2.554 | 3.244 | 4.214 | 5.13 | |||
76.2 | 3 | 2.345 | 3.084 | 3.914 | 5.094 | 6.19 | |||
88.9 | 3 1/2 | 2.729 | 3.609 | 4.584 | 5.974 | 7.27 | |||
101.6 | 4 | 4.134 | 5.254 | 6.854 | 8.35 | ||||
114.3 | 4 1/2 | 4.654 | 5.924 | 7.734 | 9.43 | ||||
Stainless Steel Tube: A/SA213, A/SA269, A/SA789, EN10216-5, GOST9941-81. |
Summary | Standards |
Standard Specification for Seamless Ferritic and Austenitic Alloy-Steel Boiler, Superheater, and Heat-Exchanger Tubes | ASTM A 213 / A 213M |
Standard Specification for Seamless and Welded Austenitic Stainless Steel Tubing for General Service | ASTM A269 / A 269N |
Standard Specification for Seamless, Welded, and Heavily Cold Worked Austenitic Stainless Steel Pipes | ASTM A312/A312M |
Standard Specification for Seamless Stainless Steel Mechanical Tubing and Hollow Bar | ASTM A511 / A 511M |
Standard Specification for Seamless and Welded Ferritic/Austenitic Stainless Steel Tubing for General Service | ASTM A789/A789M |
Standard Specification for Seamless and Welded Ferritic/Austenitic Stainless Steel Pipe | ASTM A790/A790M |
Standard Specification For Seamless Stainless Steel Tubes,cold and hot finished | GOST9941-81 |
Standard Specification For Seamless Stainless Steel Tube for Pressure purposes | EN 10216-5 |
A269 A213 A312 A789 GOST9941 EN10216-5 Standard Tolerance for Stainless Steel Seamless Tube Pipe
Standard | Outside Diameter Tolerance(mm) | Thickness Tolerance(mm) | Length Tolerance (mm) | |||
ASTM A269 | D<12.7 | ±0.13 | ±15% | +3.2 / -0 | ||
(12.7~38.1] | ±0.13 | ±10% | ||||
[38.1~88.9) | ±0.25 | +4.8 / -0 | ||||
[88.9~139.7) | ±0.38 | |||||
[139.7~203.2) | ±0.76 | |||||
ASTM A213 | D<25.4 | ±0.1 | D≤38.1 | +20%/ -0% | D≤50.80 | +3 / -0 |
[25.4~38.1] | ±0.15 | |||||
(38.1~50.8) | ±0.2 | D>38.1 | +22%/ -0% | D>50.8 | +5 / -0 | |
[50.8~63.5) | ±0.25 | |||||
[63.5~76.2) | ±0.30 | |||||
[76.2~101.6] | ±0.38 | |||||
(101.6~190.5] | +0.38 / -0.64 | |||||
(190.5~228.6] | +0.38 / -1.14 | |||||
ASTM A312 | [10.29~48.26] | +0.4 / -0.8 | 10.3~73 | +20% / -12.5% | +6 / -0 | |
88.9~457 T/D≤5% | +22.5% / -12.5% | |||||
(48.26~114.30] | ±0.80 | 88.9~457 T/D>5% | +15% / -12.5% | |||
(114.30~219.08] | +1.6 / -0.8 | 508above T/D<5% | +22.5% /-12.5% | |||
(219.08~457.20] | +2.4 / -0.8 | 508above T/D>5% | +15%/-12.5% | |||
ASTM A789 | D<12.7 | ±0.13 | ±15% | +3 / -0 | ||
[12.7 to 38.1) | ±0.13 | ±10% | ||||
[38.1 to 88.9) | ±0.25 | +5 / -0 | ||||
[88.9 to 139.7) | ±0.38 | |||||
[139.7 to 203.2) | ±0.76 | |||||
ГОСТ 9941-81 | [5~10] | Normal:±0.30 High:±0.20 Higher:±0.15 | T:0.2 | Normal:±0.05; High:±0.03 | / | |
T:0.3~0.4 | Normal:±0.07; High:±0.05 | |||||
T:0.5~1.0 | Normal:±0.15; High:±0.10 | |||||
[11~30] | Normal:±0.40 High:±0.30 Higher:±0.20 | T:1.2~3.0 | Normal:+12.5% / -15%; High:±12.5%; Higher:+12.5% / -10% | |||
T:3.5~7.0 | Normal:±12.5%; High:+12.5% / -10%; Higher:±10% | |||||
[32~95] | Normal:±1.2% High:±1% Higher:±0.8% | T:7.5~8.5 | Normal:+12.5% / -10%; Higher:±10% | |||
EN10216-5 | D3 | ±0.75% / ±0.30mm | T3 | ±10%/ ±0.20mm | L≤6m | +5 +0 |
D4 | ±0.5% / ±0.10mm | T4 | ±7.5% / ±0.15mm | ≥6~12M | +10-0 |
Application Area
High Quality Control Process
Product Application
Company Profile

Zhongzheng Stainless Steel Co., Ltd. is a China-based manufacturer specializing in R&D, production, and distribution of stainless steel products. Established in the early 2000s, it serves industries including construction, machinery, food/medical equipment, and energy with precision tubes, sheets, profiles, and custom components.
Contact Us
- Zhongzheng Stainless Steel Co., Ltd.
- Contact nameLaijing Bu Chat Now
- AddressRoom 104-07, Building 5, Jinghu Technology Park Huanajinghu Garden, Donglihu Subdistrict Dongli District,
Product Categories
New Products
-
Round A106 Gr. B API 5L Seamless Pipes for Pipeline Transportation
-
Od 76mm Wt 2mm Length 4m 304L Cold Rolled Seamless Stainless Steel Sanitary Pipe
-
ASTM 316 1cr17ni12mo2 S31600 X5crnimo1810 1.4571 Stainless Steel Seamless Tube Pipe for Aircraft Parts
-
Hot Selling ASTM 316L 273*15*5000mm Stainless Steel Pipe for Fluid Delivery Pipe
-
316 316L 310S 904L Stainless Steel Coil Roofing Sheet
-
Manufacture High Quality Matirials ASTM 304 304L 316 316L 321 347 440 441 Stainless Steel Round Square Pipe
-
Highly Corrosion Resistance AISI SUS304 SUS304L SUS316 SUS316L SUS321 SUS347 SUS310 SUS309 No. 1 10mm Stainless Steel Cold Drawing Thick Pipes
-
Excellent Price Boiler Tubes SUS304 08X18h10 12X18h10t 12X18h9t 20X23h18 10X17h13m2t Stainless Steel Stove Pipe
-
1Cr13 2Cr13 3Cr13 1cr17 304 Ba Stainless Steel Seamless Pipe for Stair Handrails
-
ASTM A240 1.4462 1.4301 S31803 S32205 201 304 316L 430 Hot Rolled Stainless Steel Sheet with High Quality
-
Hot Sale Factory Direct ASTM A240 304 316 321 Stainless Steel Sheet 1mm 2mm 3mm Cold Rolled Sheet
-
ASTM A240 253mA Uns S30815 DIN 1.4835 Super Stainless Steel Sheet Plate 201 304 316 316L Steel Sheet
-
ASTM A240 High Quality Cold Rolled 2b No. 1 201202 304 316L 310S 317L 316ti 430 410s Stainless Steel Sheet
-
China Factory Ba Mirror ASTM A240 310S/Uns S31008/En 1.4845/JIS SUS310S High Temperature Resistant Stainless Steel Plate
-
ASTM A240 DIN 201 304 304L 316 316L 321 S32205 S32750 Cold Drawn Stainless Seamless Steel Tube Pipe
-
Norsok Standard M-650 ASTM A240 S32205 Hot Rolled Duplex Stainless Steel Plates
-
Norsok Standard M-650 ASTM A240 S32205 Hot Rolled Duplex Stainless Steel Plates / Sheets
-
ASTM A240/A240m 304 Stainless Steel Sheet/Plate 2b/Ba/No. 1 Finish Ss 202 304L 316 316L 321 309S 310S 904L 430 2205 2507 Metal Inox Steel Sheet Plate
-
ASTM A240 S31803 Duplex Sheet Manufacturer in India, SA 240 Duplex Uns S32205 Coil Suppliers in China
-
Selling in Stock ASTM A240 Type 2205 Duplex Stainless Steel Sheet & Plate 2205 Duplex Stainless Steel Plate Price
-
Duplex 2205 Sheet, Duplex 2205 Plate, Manufacture Duplex Steel 2205 Sheet, ASTM A240 Duplex 2205 Sheet
-
ASTM A240 Type 2205 Sheet Stockholder, SA 240 Gr 2205 Coil Suppliers
-
S31803 Duplex Steel Plate S32205 2205 Stainless Steel Plate
-
B24511 S30408 S31603 S30403 S32205 S31803 S32750 S32760 Stainless Steel Boiler Plate
Popular Searches
- stainless steel
- Steel Pipe
- alloy steel
- Carbon Steel Pipe
- seamless pipe
- stainless steel tube
- stainless steel tubing
- Seamless Stainless Steel Pipe
- Ss Pipe
- seamless tube
- Alloy Steel Pipe
- Steel Pipe Tube
- seamless steel tube
- Boiler Pipe
- stainless steel seamless tube
- Steel Round Pipe
- boiler tube
- all grade
- square pipes
- cold drawing steel tube
- cold rolling
- ss316l
- tp304
- Astm A213 Tube
- wall panel
- container house
- water heater
- Mining Dump Truck
- shock absorber
- stabilizer link
Find Similar Products By Category
- Metallurgy, Mineral & Energy > Steel & Products > Steel Pipe & Tube
- Please Enter your Email Address
- Please enter the content for your inquiry.
We will find the most reliable suppliers for you according to your description.
Send Now-
Laijing Bu
Hi there! Welcome to my shop. Let me know if you have any questions.
Your message has exceeded the limit.
- Contact supplier for lowest price
- Customized Request
- Request Sample
- Request Free Catalogs
Your message has exceeded the limit.
-
Purchase Quantity
-
*Sourcing Details
Your inquiry content must be between 10 to 5000 characters.
-
*Email
Please enter Your valid email address.
-
Mobile
