1C31227G01 EMERSON High-speed Digital Input Module

Guizhou Yuanmiao Automation Equipment Co., Ltd.
1Yr
1C31227G01 EMERSON High-speed Digital Input Module thumbnail-1
1C31227G01 EMERSON High-speed Digital Input Module thumbnail-2
1C31227G01 EMERSON High-speed Digital Input Module thumbnail-3
1C31227G01 EMERSON High-speed Digital Input Module thumbnail-4
1C31227G01 EMERSON High-speed Digital Input Module thumbnail-5
1C31227G01 EMERSON High-speed Digital Input Module photo-1
1C31227G01 EMERSON High-speed Digital Input Module photo-2
1C31227G01 EMERSON High-speed Digital Input Module photo-3
1C31227G01 EMERSON High-speed Digital Input Module photo-4
1C31227G01 EMERSON High-speed Digital Input Module photo-5
Negotiable MOQ: 1 Piece (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Material:
Other, Global universal model
Condition:
Other, Global universal model
Task:
Other, Global universal model
Contact Supplier Request Quote Chat Now
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Material Other, Global universal model
Condition Other, Global universal model
Task Other, Global universal model
Mathematical Model Other, Global universal model
Signal Other, Global universal model
Customized Non-Customized
Structure Other, Global universal model
Operating temperature -40℃~+85℃
Humidity 5%~95% (non-condensing)




Many products are not on the shelves yet, please contact us for more models.





1C31227G01 EMERSON User Manual

 1C31227G01 is a high-speed digital input module designed for Emerson's Ovation Distributed Control System (DCS). It is primarily used for precise monitoring and control in industrial automation environments. Below is a detailed overview:
Technical Specifications

  • Input Type: Digital (dry contact, TTL/CMOS compatible)

  • Number of Channels: 16 channels (configurable in groups)

  • Input Voltage Range: 24V DC (19.2–28.8V DC)

  • Logic Threshold:

    • High: ≥15V DC

    • Low: ≤5V DC

  • Response Time: ≤1ms (typical)

  • Isolation: Channel-to-channel and channel-to-chassis isolation (500Vrms)

  • Power Supply: 24V DC (shared with Ovation backplane)

  • Power Consumption: ~5W

  • Operating Temperature: -40°C to +70°C

  • Storage Temperature: -40°C to +85°C

  • Humidity: 5–95% non-condensing

  • Protection Class: IP20 (front panel)

  • Dimensions: 133mm (W) × 127mm (H) × 76mm (D)

  • Weight: ~0.6kg


1C31227G01 (2)


Product Features

  1. High-Speed Sampling:

    • Capable of capturing rapid state changes with ≤1ms response time, ideal for event timing applications.

  2. Configurable Input Groups:

    • Channels can be grouped into 4 independent groups for flexible configuration.

  3. Redundant Power:

    • Supports redundant power supplies for enhanced system reliability.

  4. Diagnostic Capabilities:

    • Built-in self-test and continuous loopback diagnostics for early fault detection.

  5. Hot-Swap Support:

    • Allows module replacement without system shutdown, minimizing downtime.

  6. EMC Compliance:

    • Meets industrial electromagnetic compatibility standards for noise immunity.



1C31227G01 (3)






Related products:


EMERSONKJ2003X1-BA2
EMERSON1C31224G01
EMERSON1C31227G01
EMERSON1X00416H01
EMERSON1C31129G03
EMERSONSE3008
EMERSON5X00605G01


Product Tags: 1C31227G01 , EMERSON , high-speed digital input module
