MJWI15-24S05 MINMAX MJWI15 Series15W DC-DC Power Supply Converters

The MINMAX MJWI15 series are cost optimized DC-DC converter modules offering 15W output power in a 1"x1"x 0.4" shielded metal package with industry standard pinout. All models provide ultra-wide 4:1 input voltage range and fixed output voltage regulation. State-of-the-art circuit topology provides a high efficiency up to 91% allowing an operating temperature range of -40℃ to +90℃ For increased temperature performance the modules are available with an optional clip-on heatsink. Further features include remote On/Off control, trimmable output voltage, under-voltage protection, overload protection, over voltage protection, short circuit protection and no min. load requirement as well. Typical applications for these DC-DC converters are battery operated equipment, instrumentation, distributed power architectures in communication and industrial electronics and other space critical applications.
