Home > Products > lead acid battery > Maintenance Free 12V 120Ah Deep Cycle GEL UPS Battery for UPS System No Reviews Yet

Maintenance Free 12V 120Ah Deep Cycle GEL UPS Battery for UPS System No Reviews Yet

FOB Price

US$ 84 - 85 / Unit

1000 Units(Min. Order)

Port shenzhen
Payment TermsT/T
Delivery Detail25 days

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Brand Name	OEM	Place of Origin	China
Model Number	K-000022	Type	Other, lead acid battery
Nominal Capacity	120AH	Nominal Voltage	12V

Product Description

Product descriptions from the supplier

Product Description

(

Maintenance Free 12V 120Ah Deep Cycle GEL UPS Battery for UPS System

rechargeable storage solar lead acid 12v inverter ups deep cycle gel batteries

Rechargeable Storage Lead Acid Solar Battery Features and Benefits:

*Environment-friendly

*Lower internal resistance

*Positive and negative plates in lead calcium tin alloy

*Superior energy density and very high power output

*Operates at a low internal pressure

*Gas recombination

*A recognized component of CE

*Lead calcium grids for extended life six months shelf lifespan at 20°C

12V 120AH Battery Spec.:

1.Dimension and Weight	L260W168H213mm 22KG
2.Functional Parameter	Nominal voltage	12V
	Nominal capacity (10 hour rate)	120AH
	Number of cells	6 cells
3.Rated Capacity at 25℃ (77℉)	10 hour rate (0.1C, 10.8V)	120AH
	3 hour rate (0.25C, 10.8V)	92.1AH
	1 hour rate (0.55C, 10.5V)	66.3AH
4.Capacity Affected by Temperature (10 hour rate)	40℃ (104℉)	103%
	25℃ (77℉)	100%
	0℃ (32℉)	85%
	-15℃ (5℉)	65%
5.Environment Temperature	Discharge temperature	-20~60℃
	Charge temperature	0~50℃
	Storage temperature	-20~60℃
6.Inner Resistance & Max. Discharge Current	Fully charged battery at 25℃ (77℉)	4.5mΩ
	Max. discharge current	1500A(5s)
	Short circuit current	5000A
7.Self-discharge at 25℃ (77℉)	Capacity after 3 month storage	91%
	Capacity after 6 month storage	82%
	Capacity after 9 month storage	73%
	Capacity after 12 month storage	64%
8.Constant Voltage Charging at 25℃ (77℉)	Cyclic use	14.4~14.9V
	Maximum charging current	25A
	Temperature compensation	-30mV/℃
	Float use	13.6~13.8V
	Temperature compensation	-20mV/℃

All-purpose
Aircraft signal
Auto control system
Alarm and security system
Communication power supply
DC power supply
ETC
Emergency light
Electric power system (EPS)
Emergency backup power supply
Electronic apparatus and equipment
Fire fighting
Golf cars
Home
Inverter
Medical equipment
Railway signal
Sloar street light
Solar power system
Security access control
Tools
Uninterruptable power supply (UPS)
Wind enegry system

Charging voltage and settings:

1. Constant voltage charging is recommended
2. Recommended float charge voltage: 2.27V/cell at 20 to 25°C
3. Float voltage temperature compensation: -3mV/°C/cell
4. Float voltage range: 2.27 to 2.30V/cell at 20 to 25°C
5. Cyclic application charge voltage: 2.40 to 2.47V/cell at 20 to 25°C
6. Max charge current allowable: 0.25°C
