Help CenterTrolley-Type Resistance Furnace 900-1200
Related Products
-
Fast Temperature Rise And Fall Speed High-temperature Lifting FurnaceUS$ 4285 - 4500MOQ: 10 Pieces -
1800 Polycrystalline Alumina Fiberboard High Temperature Mesh Belt FurnaceUS$ 4285 - 4500MOQ: 10 Pieces
-
High-power SPK-Silicon Nitride Ceramic IgniterUS$ 10 - 50MOQ: 10 Pieces
-
280~350W SPK2 - Silicon Carbide Ceramic IgniterUS$ 10 - 50MOQ: 10 Pieces
-
Car Ceramic Glow Plugs SPK3 - Silicon Nitride Ceramic Glow Plug LgniterUS$ 10 - 50MOQ: 10 Pieces
First, the use of trolley resistance furnace
All-fiber trolley resistance furnace is a cycle furnace, a large industrial furnace, mainly for the general large, medium-sized castings or alloy parts at rated temperature for heat treatment purposes.
Second, trolley resistance furnace structure
The car furnace by the furnace (including furnace lining), door, furnace car, door lifting mechanism, carriage traveling agencies, heating elements, temperature control system, temperature records and other components.
Technical parameters
Model |
Rated power |
Rated temperature |
Chamber size |
Furnace hearth size |
Weight(kg) |
SPK-125 |
125 |
900/1200 |
1800*900*650 |
2700*1750*2100 |
3000 |
SPK-150 |
150 |
900/1200 |
2000*1000*700 |
2900*1850*2150 |
4500 |
SPK-220 |
220 |
900/1200 |
2400*1200*800 |
3300*2050*2250 |
7000 |
SPK-280 |
280 |
900/1200 |
3000*1200*1000 |
3900*2050*2450 |
10000 |
SPK-360 |
360 |
900/1200 |
3600*1500*1000 |
4500*2350*2450 |
12000 |
