ABB Bailey Analog Input Module IMASI13
Monitoring process variables such as temperature, pressure, flow, and level
Interfacing with sensors and transmitters
Data acquisition and logging
Industrial automation tasks
Manufacturers: ABB, Bailey
Model(s):ABB Bailey Infi 90, ABB Bailey Infi 90 and Net 90
Product No. : IMASI13
Product Type : Analog Input Module
Power requirements, Operating voltage : 5 VDC at 500 mA typical, maximum 750 mA
Overvoltage category (IEC 61010-1)
I for circuit above 150V
II for circuit below 150V
Analog input channels : 16 independently configured channels
Thermocouples
Type E, J, K, L, N (14 AWG), N (28 AWG), R, S, T, U
Chinese type E and Chinese type S
3-wire RTD
Please contact me get more information
Email:Mia@cwlyautomation.com
VK/Whatsapp/Telegram:+8613667120925
Website:
100 O platinum: U.S. Lab. Standard
100 O platinum: U.S. Industry Standard
100 O platinum: European Standard
120 O nickel
10 O copper
Chinese 53 O copper
Millivolt : -100 mV to +100 mV, 0 to 100 mV
High level
1 to 5 VDC, 0 to 5 VDC, 0 to 10 VDC
-10 VDC to +10 VDC, or user specified range
within -10 VDC and +10 VDC
Current : 4 to 20 mA, system or external power
Ambient temperature : 0 to 70 C (32 to 158 F)
Relative humidity
5% to 95% up to 55 C (131 F) (noncondensing)
5% to 45% at 70 C (158 F) (noncondensing)
Pollution degree: 1
Altitude : Sea level to 3 km (1.86 miles)
Air quality : Noncorrosive
Weight : 0.91 Kg
Shipping Weight : 2 Kg
Estimated Shipping Size: Dimensions: 7.0" x 2.0" x 13.0"
(17.8 cm x 5.1 cm x 33.0 cm)
Catalog Description: IMASI13, Analog Input Module
Alternate Part Numbers: YIMASI13, RIMASI13, PIMASI13
Common Typographical Errors: IMASI-13, IMASII3, IMAS113, 1MA5113, 1MA5II3, IMA51I3
