Home > Products > Suit for construction machinery > S410G Turbo 177148 0R7310 169227 471142-5005 0R7923 137-4832 1679271 turbocharger for CAT Truck 3406E 3406C C16 C15 engine

S410G Turbo 177148 0R7310 169227 471142-5005 0R7923 137-4832 1679271 turbocharger for CAT Truck 3406E 3406C C16 C15 engine

FOB Price

Negotiable

1 (Min. Order)

Payment TermsT/T Credit Card

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Description

S410G Turbo 177148 0R7310 169227 471142-5005 0R7923 137-4832 1679271 turbocharger for CAT Truck 3406E 3406C C16 C15 engine

Product Description

Specification

Part Number	177148
Previous Version	169227, 170354, 704604-0007, 466445-0018, 466445-0023, 466445-9023, 471142-0005, 471142-9005, 471142-0003, 466445-0015, 466445-0021, 466445-9021, 471142-5005
OE number	0R7310, 0R7923, 1080004R, 160-6201, 1606201, 167-9271, 1679271, 177148, 177148R, 196-5951, 1965951, 477148, 0R7152, 0R6989, 0R7203, 0R7223, 0R6986, 0R7201, 0R7299, 166-6752, 141-8937, 124-3032, 136-6390, 146-4328, 141-8939, 124-3035, 137-4832
Description	Tractor, Truck
CHRA	174248 (169062, 161-6780, 10R-0510, 0R7287, 0R-7143, 0R7143, 136-7620, 1367620, 474248) $450.00 NEW IN STOCK, MADE IN USA
Turbo Model	S410G, GTA470201BS, GT4702, BTG7513, GT500201BS
Prefix	2WS, R1D, 6NZ, 9NZ, C2A, AKN
Engine	3406E, 3406C, C16, C-12, C-15, MT735
Displacement	14.64L, 14640 ccm
S/N	OKC150148
RPM	1800
KW	317/404/550/355/475 HP
Fuel	Diesel
Bearing Housing	174246 (Oil Cooled) $81.94 NEW IN STOCK
Turbine Wheel	169346 (Ind. 91.46 mm, Exd. 81.66 mm, Trm 14.4, 10 Blades) $162.00 NEW IN STOCK
Comp. Wheel (Hipped)	171691 (Ind. 74.57 mm, Exd. 105.3 mm, Trm 7.97, 7+7 Blades, Superback) $97.15 NEW IN STOCK
Back plate	167783 $43.34 NEW IN STOCK
Heat shield Number	167790 $18.78 NEW IN STOCK
Repair Kit	318396 (318397)(1253400750) $89.90 NEW IN STOCK
Turbine Housing	NEW IN STOCK
Compressor Cover
Actuator	446131-0046 $117.92
Gasket Kit	318417 $17.44
Gasket oil inlet	129119 (210019, 201049, 9737, 1S6595, 210019-0000, 409266-0003, 3819900, 129120)(417378 Replaced by 420641)(1900000035) $4.38
Gasket (oil outlet)	210018 (210018-0000, 129120, 409267-0002, 201048, 157602, 3037537, 3709738, 3500682, 201048, 1S4810, 9988, 9738, 3519763)(1900000025) $4.38
Replaced By	704604-0007 (0R7310, 1679271, 167-9271, 704604-5011 (1965951. 196-5951, 160-6201))
Manufacturer	Schwitzer, BWTS USA
Condition	NEW
NOTE	The 174260 and the 177148 are very similar turbos, the wheel measurements are exactly the same, the only difference is the exhaust housing, the 174269 uses a W/G 1.10 A/R housing while the 177148 uses a 1.32 A/R housing the overall horsepower different between the two and what they will support is 100 hp, the larger housing allows the engine to breathe a little better and will support 600 hp versus 500 hp for the smaller housing.
Replaced By	471120-0001

Application:
1994-07 Caterpillar Engine Truck 3406E, 3406C, C16 Engine
