Home > Products > Suit for construction machinery > Btv8501 Turbo 466807-0001 466807-5001S 10r-0435 118-0398 1989914 10r0435 207-1351 Turbocharger for 3508b 3516b Engine

Btv8501 Turbo 466807-0001 466807-5001S 10r-0435 118-0398 1989914 10r0435 207-1351 Turbocharger for 3508b 3516b Engine

FOB Price

Negotiable

1 (Min. Order)

Payment TermsT/T Credit Card

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Description

Btv8501 Turbo 466807-0001 466807-5001S 10r-0435 118-0398 1989914 10r0435 207-1351 Turbocharger with 3508b 3516b Engine

Welcome to contact us :

November Gao.

Mob/Wechat/WhatsApp: 8618912476630

Products description

Part Number	466807-5001S
Previous Version	466807-0001, 466807-9001, 466807-0003, 466807-5004S, 466807-5005S, 466807-1
OE Number	1180398, 118-0398, 1989914, 10R0435, 207-1351, 2071351, 10R-0435, 2071351
Description	Gen Set, Industrial Engines and Power Units, Generator Set Oil Field Land Rig
CHRA	449073-0019 (449073-5019S, 712371-0028, 1488171, 10R0434, 2032155) $1,910.61
Turbo Model	BTV8501, BTVA8501
Engine Model	3508 DITAJWAC GS, 3516B DITASCAC GS
Engine Manufacturer	Caterpillar
Displacement	34.5L, 34500 ccm, 8V Cylinders
Fuel	Diesel
Power Module	PM3508, PM3516
Gen Set Engine	3516B, 3508B
Generator	3508B, 3516B
S/N	1FZ1-UP, 1HZ1-155, 1HZ1-255, 1FZ1-585, 2JW1-235, 1NW1-133, 4GM303-640, 6HN303-1253, 7RN198-1576, 6PN446-698, 7RN00001-UP, 6HN00001-UP, 6PN00001-UP, 4GM00001-UP, 1NW00001-UP, 5KW00001-UP, 8NW00001-UP, 2JW00001-UP, BPD00001-UP, BLM00001-UP
Bearing Housing	449072-0001
Turbine Wheel	449236-0001
Comp. Wheel	449207-0002
Back plate	448797-0011 (carbon seal) $284.86 NEW IN STOCK
Heat Shield	407657-0009
Repair Kit	468267-0007
Turbine Housing	441122-0118 (1052898)
Compressor Cover	443892-0030 (709557-0009, 1260911, 2465826, 1933279)
Turbine Housing AR	1.23
Replaced By	466807-0006
Gasket (turbine inlet)	409038-0001 (1215736, 7M7273)
Gasket oil inlet	129119 (1900000035)(201049, 9737, 1S6595, 210019-0000, 409266-0003, 3819900)
Gasket (oil outlet)	129120 (210018-0000, 409267-0002, 3709738, 3500682, 201048, 1S4810, 9988, 9738, 3519763) (1900000025)
NOTE	Partially restricted, Boreless

Applications

2001- Caterpillar Generator Set Industrial Engines and Power Units with 3508B, 3516B Engine

Payment Terms

• T.T

Package & Delivery

• Neutral Carton

• Send within 7 days

1.Our main products are turbocharger,turbo cartridge/chra/core,nozzle rings,electric actuator valve ,turbo repair kit and so on

2.We usually supply original size turbo ,and also we can modify size according to customers requirement .

3.Our own factory ,high quality and lowest price .

4.Our aim is :quality assurance ,credit first ,mutual benefit ,customers first .

Product show

Packages

plastic paper, shock bubble, neutral carton,pallet or as your requirements

Company Information

CVE Electron Beam Welding from UK

Studer CNC grinding machine from Switzerland

Okuma CNC machine from Japan

Schenck balancing machine from Germany

Production capacity

Exhibition show

Booshiwheel has attended the Auto exhibition in Thailand ,Turkey,Dubai, Russia,Germany,U.S.A and Panama in 2018 year

Company Profile

1.Wuxi Booshiwheel Power Technology Co,Ltd.,established in 2002,is engaged in designing and producing turbochargers and turbo parts that are used in vehicle and engineering machinery.We can also provide maintenance and technological services.

2.The company has imported Japanese advanced equipments,such as assembly line,processing production line and high speed balance,as well as the latest testing facilities.

3.The company's business concept are "make contribution to the development of society by technology" and "talent is the biggest and unique wealth",focus on manufacturing global the most cost-effective turbochargers.

Last ,we are looking forward to cooperating with you .

FAQ
1:Are you factory or only company?

we have factory to produce turbo products ,such as ship turbos,performance turbos,aftermarket turbos,etc .And also we have the agent for some other brand.

2:Why we can choose you?
1):Reliable-we are the real company, we dedicate in win-win.
2):Professional-we offter the turbo products exactly you want.
3):Factory-we have factory,so have compective price,fast delivery time,high quality goods.

3:How about the shipping cost?
If your goods is not large,we can send goods to you via express,such as FEDEX,DHL,EMS,TNT,etc.if your goods is large ,we will send to u via sea or air,we can quote the price base on EXW,FOB,CIF&CNF as you like, you can choose whether to use our forwarder or yours.

4:How about the price ? Can you make it cheaper?
the price depends on the item your demand quantity,Final quotation according to receiving full description of the item you want.

5:How about the sample time ?What is the payment ?
Sample time: 3-10days after e-proof confirmed and your payment received. T/T, 30% deposit ,and the balance before the shipment.

Welcome to inquiry!
