1310nm 2X2f Mechanical Optical Switches

FOB Price

US$ 10 - 50 / Piece

1 Piece(Min. Order)

Port Nanning
Payment TermsT/T
Delivery Detail7 days

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Brand Name	xionghua		Place of Origin	China
Model Number	XH-OSW-2X2F

Product Description

XH-OSW-2X2F full-switching mechanical optical switch is a kind of optical path control device, which has the function of controlling the optical path and converting the optical path; it can realize the two-way direct and cross function of the optical path. It plays an important role in optical communication applications. Optical switches are mainly used in multi-channel optical monitoring in optical transmission systems, LAN multi-light source/detector automatic switching, and optical sensing multi-point dynamic monitoring system optical test systems for optical fibers, optical devices, networks and field engineering optical cables Test; optical device installation and adjustment.

Features

Low insertion loss, wide wavelength range

Low channel crosstalk, high stability, high reliability

Simple control, small size, easy to embed in the circuit board

Locking and non-locking control types can be selected

Performance

Parameter	Parameter Value
Model	XH-OSW-2x2F
Insertion Loss(dB)	Typical value:0.5 Max:1.0
Wavelength Range(nm)	850~1310	1260~1650
Working Wavelength(nm)	850/980/1310	1310/1550/1625
Return Loss(dB)	MM ≥ 30 SM ≥50
Channel Crosstalk(dB)	MM ≥ 35 SM ≥55
PDL(dB)	≤0.05
WDL(dB)	≤0.25
TDL(dB)	≤0.25
Repeatability(dB)	≤±0.02
Lifetime(Times)	≥107
Switching Time(ms)	≤8
Transmission power(mW)	≤500
Operating Voltage(V)	3 or 5
Operating temperature(ºC)	-20~+70
Storage temperature(ºC)	-40~+85
Weight (g)	16
Dimension(mm)	(L)27.0×(W)12.5×(H)8.4±0.2

Tip: The above are commonly used optical switch parameters, if you have other requirements, please consult and customize.
