PTFE HEPA ULPA Filter

Advantages

 High toughness, strong damage resistance, in harsh environments,with excellent acid resistance (including

fluoric acid), alkali resistance, resistance to organic substances.

 Low volatility (boron-free) clean material, reducing the release of impurity waste gas (boron, potassium,silicon, etc.);

no metal pollutants.

 Compared with ordinary glass fiber materials, the pressure loss is reduced by about 40%, which reduces energy consumption, saves space and reduces weight.

 Lightweight, good sealing, compact structure, easy installation, high efficiency, low resistance and low operating cost.

Product Characteristics

Frame: Anodized aluminum

Header: Box type / Single header / Double header

Media: PTFE fiber

Efficiency:

H13 (EN 1822) / MERV 17-18 (ASHRAE 52.2)

MPPS: ≥99.95% / DOP: ≥99.99%@0.3 μm

H14 (EN 1822) / MERV 19 (ASHRAE 52.2)

MPPS: ≥99.995% / DOP: ≥99.999%@0.3 μm

U15 (EN 1822)/MERV 20 (ASHRAE 52.2)

MPPS: ≥99.9995% / DOP: ≥99.9999%@0.12 μm

U16 (EN 1822)/MERV 20 (ASHRAE 52.2)

MPPS: ≥99.99995% / DOP: ≥99.99999%@0.12 μm

Separator: Hot-melt adhesives

Sealant: EPDM

Max. Temperature: ≦ 250°C

Max. Humidity: ≦ 100% RH

Applications

PTFE HEPA filter / ULPA filter is widely used in semiconductor, electronics, precision manufacturing, bio-pharmaceutical and other industries.
