TIP33CG onsemi Bipolar Transistors - BJT 10A 100V 80W NPN

Mfr. #:

TIP33CG

Manufacturer: onsemi

Product Category: Bipolar Transistors - BJT

RoHS: Details

Mounting Style: Through Hole

Package / Case: TO-247-3

Transistor Polarity: NPN

Configuration: Single

Collector- Emitter Voltage VCEO Max: 100 V

Collector- Base Voltage VCBO: 100 V

Emitter- Base Voltage VEBO: 5 V

Collector-Emitter Saturation Voltage: 1 V

Maximum DC Collector Current: 10 A

Pd - Power Dissipation: 80 W

Gain Bandwidth Product fT: 3 MHz

Minimum Operating Temperature: - 65 C

Maximum Operating Temperature: + 150 C

Series: TIP33C

Packaging: Tube

Brand: onsemi

Continuous Collector Current: 10 A

DC Collector/Base Gain hfe Min: 40

Height: 16.2 - 4 mm

Length: 15.2 mm

Product Type: BJTs - Bipolar Transistors

factory pack quantiy: 30

Subcategory: Transistors

Technology: Si

Width: 4.9 mm

Unit Weight: 0.229281 oz
