Zte ZXD2400 Power module Communication power module

Zte ZXD2400 50A rectifier module adopts a new large-capacity device IGBT, which simplifies the circuit structure and improves the reliability;

Zte ZXD2400 50A rectifier module adopts soft switching power conversion technology within the full load range to ensure high conversion within the full load range

Efficiency, but also can improve the switching frequency, make it possible to small power, lightweight, electromagnetic interference is also greatly reduced;

The wide AC input voltage range is suitable for the vast rural and mountainous areas of China.

Ac input power factor is close to 1;

Zte ZXD2400 50A rectifier module to achieve constant power type output characteristics, AC power off later battery charging, in the battery voltage is low, can provide 20% higher than the rated output current. When the load capacity is the same, the number of single modules can be reduced, thus saving the investment for the user;

Built-in monitoring CPU and LCD module, can display the rectifier parameters in real time;

On the keyboard, you can set protection alarm parameters and adjust variables such as the equalized float charging output voltage and output current limiting point.

Perfect three-remote interface function, provides RS485 communication interface, can realize centralized monitoring;

The input and output have perfect and reasonable protection measures, which not only improve the reliability of the rectifier, but also protect the electrical equipment.

Convenient input/output interface, can achieve direct hot swap;

Advanced modular design, multiple parallel automatic current sharing;

Fan temperature control work, improve the reliability of the system;

Zte ZXD2400 50A rectifier module professional input and output filtering circuit and shielding insulation design makes it have good electromagnetic compatibility and minimal electromagnetic radiation.
