1250 Cable Coiling Machine
- Shanghai
- T/T L/C
- 40 days
You May Like
-
1246 Automatic Wire and Cable Coiling and Packing Machine
-
Fine Copper Wire Drawing Machine With Annealing
-
Super Fine Copper Wire Drawing Machine
-
B22DT High Speed Copper Fine Wire Drawing Machine With Annealing
-
High Speed Super Copper Fine Wire Drawing Machine
-
Intermediate Wire Drawing Machine With Annealing
Product Details
| Brand Name | Zhangjiagang Brilliant | Place of Origin | China | |
| Model Number | 630 | Usage | Drawing |
Product Description
Technical Parameter:
| Model | 630mm | 1250mm | 1250-1600mm |
| Applicable wire range | 0.5-6mm2 | 10-70mm2 | 10-240mm2 |
| Traversing tension | Automatically | ||
| Main motor speed | 0-600 r/min | 0-300 r/min | 0-300 r/min |
| Loading bobbin type | Lever-type | Electric type | Electric type |
| Pay-off bibbin model | 400-630mm | 800-1250mm | 1000-1600mm |
| Tapping model | Outside Dia less than 320mm Inner Dia. 120mmWidth30-100mm | Outside Dia less then600mm Inner Dia. 200300mm Width60-150mm 150-200mm | 50-250 |
| Power | 2.2kw | 3kw | 4kw |
| Meter counter structure | Type of wheel pressure | Double wheel type with air pressure | Double wheel type with air pressure |
| Induction type/ Measurement accuracy | Rotary encoder/0.5% | Rotary encoder/0.5% | Rotary encoder/0.5% |
Package and shipment:
Online Installation and testing:Engineer dispatch:
Customer Feedback:
FAQ:
1. Who are we?
Brilliant is in suzhou.Factory is located in Zhangjiagang City.Established in 2011, with 12 years of experience in wire and cable field trade.
It will take us 1hour to the nearest seaport in Shanghai.
2. How can we guarantee quality?
1) Bring client to user's factory to see machine production condition and final cable quality.
2) With testing wire before shipment.
3) Engineer will be arranged after delivery.
4) Machinery parts are guaranteed for 12 months, electrical parts are guaranteed for 6 months.
5) Sales person and engineer is online for 24 hours to solve any problems.
3.What our main products?
Copper wire drawing machine, double twist bunching machine, electric cable extruder, coiling and packing machine, textile braiding machine etc.
4. How long is your delivery time?
30-60 days for goods after receiving order.
