Mitsubishi Servo Motor HG-KR73BJ With Oil Seal

Mitsubishi MR-J4 series servo motor 750W HG-KR73J and HG-KR73BJ product specifications:

[Continuous characteristic] Rated output 750w, rated torque 2.4 N.m

[Torque] 8.4N. m

[Rated speed] 3000r/min

[Speed] 6000r/min

[Instantaneous allowable speed] 6900r/min

[Power ratio under continuous rated torque] Standard 45.2kW/s, with electromagnetic brake 41.6kW/s

[Rated current] 4.8A

[Current] 17A

[Inertia J] Standard 1.26, with electromagnetic brake 1.37

[* * * Load inertia ratio] less than 25 times

[Speed and position detector] Position and increment share a 22-bit encoder (resolution of servo motor per revolution: 4194304pulses/rev)

[Oil seal] Yes

[Heat resistant glass] 130 (B)

[Structure] Fully enclosed self-cooling (protection grade: IP65)

[Vibration level] V10

[Allowable load of shaft] L 40mm, radial 392N, axial 147N

[Weight] Standard 2.8kg, with electromagnetic brake 3.8kg

HG-KR43BJ Electromagnetic Brake Specification

[Form] Non-excitation action type (spring braking) safety braking

[Rated voltage] DC24V (- 10%~0%)

[Power consumption] 10W

[Coil resistance] 57.0 Ω

[Inductance] 0.13H

[Static friction torque of electromagnetic braking] 2.4N. m

[Release delay time] 0.04 seconds

[Brake delay time] DC cut-off 0.02 seconds

[Allowable braking energy] 64J per brake, 640J per hour

[Service life of electromagnetic brake] 20000 times of braking, 22J of single braking

HG-KR73J,HG-KR73BJ,HG-KR73JK,HG-KR73BJK
