Features
●Long service life
●Large volume, low resistance and large amount of dust
●For large volume air conditioning and ventilation system
Standard specification
※ Media:Wet-laid glass fiber
※ Frame:ABS plastic,aluminum sheet,galvanized steel sheet.
※ V-shaped filter design to maximize media and filter life for optimal performance
※ Pleat media is sealed in polyurethane around the perimente of filter ensuring a
leak design eliminating particle by-pass
※ Leakage testing by unit before leaving factory and provide testing report
※ Different sizes and specifications are available.
※ Efficiency:H11(EN1822),≥95% @ MPPS ≥99% @ 0.3um
H13(EN1822),≥99.95% @ MPPS ≥99.99% @ 0.3um
H14(EN1822),≥99.995% @ MPPS ≥99.999% @ 0.3um
※ Recommended final Pressure drop:600Pa
Standard specification
model | Outside dimensions | Rated air flow | Imitial resistance(Pa) | Efficiency | v slots |
CJ--H4-HV1 | 305×610×295 | 1600 | ≤250 or ≤150（HV） | ≥99.99 | 4V |
CJ--H4-HV2 | 610×610×295 | 3200 | ≤250 or ≤150（HV） | ≥99.99 | 4V |
CJ--H4-HV3 | 305×610×295 | 2000 | ≤250 or ≤150（HV） | ≥99.99 | 5V |
CJ--H4-HV4 | 610×610×295 | 4000 | ≤250 or ≤150（HV） | ≥99.99 | 5V |
According to user requirements to customize different specifications and types of filters
