The NI PXI-8820 is a PXI embedded controller launched by National Instruments (NI). The "2.2" typically refers to the processor clock speed of 2.2GHz. Here are its parameter details:
Key Parameters

  • Product Type: PXI Embedded Controller.

  • Processor: Intel Celeron 1020E dual-core, 2.2GHz, 2MB cache.

  • System Bandwidth: Up to 1GB/s.

  • Slot Bandwidth: 250MB/s (four x1 PCI Express connections).

  • Memory: Standard 2GB DDR3L (1333MHz), expandable to 8GB.

  • Storage: 250GB or larger SATA hard drive (laptop form factor). Supports Windows 7 installation from USB devices (CD/DVD-ROM) or external SCSI CD-ROM via PXI-SCSI adapter.

  • Form Factor: 2-slot 3U PXI Express module.

  • Weight: Approximately 1.87lb (0.85kg).

  • Standard I/O Interfaces: 1 DisplayPort video interface, 1 RS-232 serial port, 1 parallel port, 4 high-speed USB 2.0 ports, 1 Gigabit Ethernet port, 1 reset button, and PXI trigger interface.

  • Trigger Function: Front-panel SMB connector supporting PXI trigger bus input/output.

  • Operating System: Compatible with 32-bit Microsoft Windows 7, also supports LabVIEW Real-Time OS.

  • Operating Temperature: 5°C to 50°C.

  • Application Fields: Suitable for industrial control, data acquisition, test and measurement, etc.
