Solar Energy System 5kw With Lithium Storage Battery off on Grid Power Staiton for House

Zonergy Corporation Verified Business License
Solar Energy System 5kw With Lithium Storage Battery off on Grid Power Staiton for House thumbnail-1
Solar Energy System 5kw With Lithium Storage Battery off on Grid Power Staiton for House thumbnail-2
Solar Energy System 5kw With Lithium Storage Battery off on Grid Power Staiton for House thumbnail-3
Solar Energy System 5kw With Lithium Storage Battery off on Grid Power Staiton for House thumbnail-4
Solar Energy System 5kw With Lithium Storage Battery off on Grid Power Staiton for House thumbnail-5
Solar Energy System 5kw With Lithium Storage Battery off on Grid Power Staiton for House photo-1
Solar Energy System 5kw With Lithium Storage Battery off on Grid Power Staiton for House photo-2
Solar Energy System 5kw With Lithium Storage Battery off on Grid Power Staiton for House photo-3
Solar Energy System 5kw With Lithium Storage Battery off on Grid Power Staiton for House photo-4
Solar Energy System 5kw With Lithium Storage Battery off on Grid Power Staiton for House photo-5
US$ 2082.39 - 8298.60 MOQ: 1 Piece
Key Specifications
Get Latest Price
Brand Name:
Zonergy
Place of Origin:
China
Model Number:
Panda 5000S-5HP~30HP
Contact Supplier Request Quote Chat Now
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen
Delivery Detail:
15 days

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Brand Name Zonergy
Place of Origin China
Model Number Panda 5000S-5HP~30HP
Application Home
Specification Normal
Output Voltage (V) 220v
Work Time (h) 24
Solar Power (W) 5kw
Load Power (W) 5kw
Distributed PV-ESS Solution
Zonergy offers solutions for the distributed Photovoltaic Energy Storage System, Including Zonergy-made Solar panels, Energy Storage Inverters, Lithium Battery Modules, and WiFi stick, to store the surplus energy from solar power generation. Our solution not only keeps the darkness away from your family when power outage, but also save extra on your electricity bill. Zonergy selects high-class core components, applies brilliant electrical and structural design, continues the concept of standardized modules, and realizes flexible expansion of nominal capacity and power. Meanwhile, Zonergy uninterruptedly investigates the product application scenarios and configures the 9-Level Safety Protection design to build a high-security, high-performing, and easy-to-install Energy Storage System.
Residential Single-phase Energy Storage System Panda Series
1. The built-in Smart Grid Management module enables power grid dispatching.
2. The switching time between on-off grid less than 10 ms secures Uninterruptable Power Supply for the load.
3. The APP-based remote monitoring offers easy maintenance and unlimited function expansion.
4. The Lithium Iron Phosphate (LFP) cell secures safe and reliable operation.
5. The 5 KWh module adopted enables variable capacity range of 5-30 kWh.
6. The automatic isolation of the faulty battery module secures smooth system operation.
7. The Degree of Protection at IP65 makes it suitable for various harsh environments for application.
Specification
System Specification
Nominal Output Power
4000 W / 5000 W / 6000 W
Capacity Range
5.12~30.72 kWh
Usable Capacity Range
4.6~27.65 kWh
Battery Chemistry
LFP (LiFePO4)
IP Protection
IP65 (Outdoor)
Warranty
5 Year Product Warranty, 10 Year Performance Warranty
Inverter Technical Specification
Model
Venus 4000-S1 / Venus 5000-S1 / Venus 6000-S1
Phase
Single Phase
Max. PV Input Voltage
600 V
MPPT Voltage Range
100 V~550 V
Max. PV Input Current
13 A / 13 A
Max. PV Input Power
6000 W / 7500 W / 9000 W
Max. MPPT Short-circuit Current
18 A /18 A
Number of Independent MPPT
2
Start-up Voltage Range
120 V
Max. Charging/Discharging Current
80 A / 100 A / 100 A
Max. Charging/Discharging Power
4000 W / 5000 W / 6000 W
Nominal Output Voltage on Grid
220 V,230 V,240 V (comply with local regulations)
Output Voltage Range on Grid
180 ~ 276 V
Rated Grid Output Frequency on Grid
50 Hz/60 Hz
Max.AC output Power
4000 W / 5000 W / 6000 W
Nominal AC Output Voltage
230 V
Communication
CAN2.0/RS485, Wifi/GPRS(optional)
Display
LCD & APP
Dimension(W*H*D) mm
540 x 450 x185
Battery Technical Specification
Module Model
Limestone 5H-P
Limestone 10H-P
Limestone 15H-P
Limestone 20H-P
Limestone 25H-P
Limestone 30H-P
Module Capacity
5.12 kWh
10.24 kWh
15.35 kWh
20.48 kWh
25.64 kWh
30.72 kWh
Usable Capacity
4.6 kWh
9.21 kWh
13.81 kWh
18.43 kWh
23.04 kWh
27.65 kWh
Nominal Voltage
51.2 V
Max. Charging/Discharging Power
2.5 kW
5 kW
5 kW
5 kW
5 kW
5 kW
Operating Temperature Range
-20 ~ +50 °C
Dimension(W*H*D) mm
650 x 620 x 180
650 x 980 x 180
650 x 1340 x 180
650 x 980 x 180
650 x + x 180
980
650 x 1340 x 180
650 x + x 180
980
650 x 1340 x 180
650 x + x 180
1340


Product Tags: solar energy system for home , solar energy storage system , solar energy system 10kw , guangdong solar energy system , complete solar energy storage systems , solar energy system off grid , solar energy battery storage system , solar energy system on-grid , port
