Portable ac dc Aluminum Inverter Tig Welder AC Dc 200a
- T/T Credit Card
You May Like
-
ac dc Cold Lift Tig 200p Welding Machine
-
ac dc Tig Welder Combo TIG-200PACDC Welding Machine
-
Everlast TIG-200PACDC Ac Dc Tig With Gas Welding Machine AC/DC TIG Pulse TIG Retop Welder AC 230V Carton BOX IGBT Pulse Provided
-
TIG Welder ac dc Aluminum Welding Machine TIG-200PACDC
-
Nbc 250 Inverter Mig Welding Machine 400 Amp Without Gas 15-20l/min 3-15m/min Bule or OEM 50/60 Hz 20-170A 40-200A 16-24V 13KG
-
Professional Aluminum Tig Welding Machine TIG-200PACDC
Product Description
Features
(1) Digital control,MCU technology,automatic parameter saving.
(2)IGBT inverter technology.
(3) Hight frequency toguarantee lighter and smaller welder with higher efficiency.
(4) Multi-function design to meet various welding demands.It is suitable for DC TIG welding,MMA welding,spot welding,pulse TIG welidng,AC TIG welding etc.
(5) Simple-to-use operator interface.
(6) Less spatter,stable arc and good shaping.
(7)Applicable for DC TIG welding of carbon steel,stainless steel,alloy steel,and other non-ferrous metals.especially for AC TIG welding of aluminum and aluminum alloy products.
ITEM | UNIT | TIG-200PACDC |
Input power voltage | V | AC230V |
Input power frequency | Hz | 50/60 |
Input Current | A | 31 |
Rated input capacity | KVA | 7.1 |
Output current range(TIG) | A | 5-200A |
Output current range(MMA) | A | 10-160 |
Pre-flow Time | S | 0.1-10 |
Post-flow Time | S | 0.5-15 |
Down Slope | S | 0-15 |
Balance | 15-85 | |
Arc Starting | HF | |
AC Frequency | 20-250 | |
Pulse Frequency | 0.2-200 | |
No-load voltage | V | 56V |
35% | 200 | |
Rated Duty Cycle | 60% | 129 |
100% | 100 | |
Electrode Diameter | mm | 1.5-4.0 |
Efficiency | % | 85 |
Protection grade | IP22S | |
Insulation Class | B | |
Dimensions | mm | 440*210*360 |
Weight | KG | 11 |
MOQ:
- The different products with different MOQ. Contact us with more details.
- If with stock, 1-5 sets could be acceptable as well.
Payment:
- TT payment would be preferred: usually 30% deposit and the balance before shipment
Delivery time:
- Within 20 days after confirming the payment
Sample Issue
- Once price and order confirmed, we will be glad to send you the required samples for reference.
First time to use this kind of machine
- There is an English manual or guide video that show you how to use machine.
- If you still have any question, please contact us by e-mail /phone / online service.
If any problem with machine after receiving
- 24 hours to support by E-mail/calling
- Free parts could be sent to you in machine warranty period.
Why choose us?
- We are welding machine MANUFACTURER,so we can offer better price and after-sale service and shorter delivery date.
- We use all new components,IGBT tube, diode,capacitor and so on imported components.
- We adopt SMT technology to decrease failure rate and it is convenient to repair the welding machine and reduce the cost of repairing,we just need to change the bad pcb board.
- We provide Warranty period of 1 to 2 years for all our items.
a. We are welding machine MANUFACTURER, so we can offer better price and after-sale service and shorter delivery date.
b. We use all new components,mosfet tube, diode, capacitor and so on imported components.
c. We adopt IGBT technology to decrease failure rate and it is convenient to repair the welding machine and reduce the cost of
repairing, we just need to change the bad pcb board.
d. We provide Warranty period of 1 year for all our items
