Home > Products > Auto bearings > 21080-3103020-02 21080310302002 Spare Parts for Lada Samara Front Wheel Hub Bearing
21080-3103020-02 21080310302002 Spare Parts for Lada Samara Front Wheel Hub Bearing
Negotiable
1 (Min. Order)
- T/T Credit Card
You May Like
-
256907AKE12 83103020 For Front Wheel Hub Bearing 2108/2109/21099 All 86-90
-
Russian Market XGB.41140.R00 6001550915 713630840 Wheel Bearing Kit for France Car Parts Size37X72.04x37
-
Factory Stock 52710 26510 IJ211001 IX35 / CRETA Auto Front Wheel Bearing Size 42x76x39 ZZ for Selling
-
Russian Market BP4L-33-047B Front Wheel Hub Bearing Kit AU0838-5LXL/L588 Size 42x80x45 ABS for Megane
-
Factory Provide Front Alex Wheel Bearing Kit 713618790 90080-36193 Size 45*84*45 for RX / ES AVENSIS Car
-
527201F000 CARNIVAL 99-01, CARNIVAL II 01-, Rear Auto Wheel Bearing Ij211001 Without Abs Size 42x76x39 zz for Selling
Product Description
Specification
Product name | Auto Front Wheel Hub Bearings |
Usage | wheel hub bearings |
Rotational Speed ingrease | 6000 |
Car Make | LADA CARLOTA, LADA CEVARO, LADA DIVA, LADA SABLE, LADA SAGONA, LADA SAMARA, LADA SAMARA FORMA |
OE NO. | 133039BCTNG2RS 13303-9BCTNG2-RS 21080310302001 21080-3103020-01 21080-3103020-02 21080310302002 256907AKE12 83103020 |
Place of Origin | China |
Brand Name | VLBG VBF |
Model Number | 713691010 |
Warranty | 12Months |
Inner diameter | 34MM |
Outside diameter | 64MM |
Height | 37MM |
Outer cage width | 37mm |
Certificate | ISO9001/TS16949 |
Number of balls pcs | 28 |
Weight | 0.445kg |
Ball diameter | 9.52 |
Steel grade | shkh-15 |
Dynamic Load Capacity.H | 31500 |
Static Lifting capacity.H | 27900 |
713691010 2108 -3103020 | Double-row angular contact ball bearing GOST 6-256907 |
Double-row angular contact ball bearing GOST 713691010
Double-row angular contact ball bearing GOST 713691010 was specially developed for operation in passenger car hub assemblies.
It has a higher load capacity than single row deep groove ball bearings, but has comparable speed characteristics. Among other things, being a radial-thrust one, it can work under conditions of high axial loads.
Bearing dimensions and characteristics
The main components of the ball bearing article 256907 are cages with grooves for balls and a rolling element assembly. The shape of the grooves provides support for the rolling elements, both radially and axially. The assembly itself is protected by contact type seals.
This bearing is a part of domestic production. The decoding of its designation can be performed according to the scheme adopted for Russian products of this type.
The dimensions of bearing 713691010 are 34x64x37 mm. Weight does not exceed 0.445 kg. At factories, this part is packed in cardboard boxes, and instructions for the installation and operation of the product are placed inside.
The dynamic load rating of the ball bearing is 31.5 kN. Static - 27.9 kN. Working frequency of rotation - 6000 rpm.
Diameter and number of balls
Diameter and number of balls
The number of rolling elements in the bearing 713691010 - 28 pcs. These are balls of a regular spherical shape with a diameter of 9.525 mm. They are made of special grades of steel (as a rule, ShKh-15) and heat-treated.
The separator can be steel, made by stamping from an alloy with a high carbon content (without additional designation), cast polyamide (E5), made of textolite (E1C17).
Analogs and modifications
Another analogue can be considered a double-row roller bearing with the same dimensional characteristics 537907. Due to the peculiarities of its design, it has a significantly higher load capacity, but a lower operating frequency.
Among the modifications of the ball bearing 713691010 are products with different types of cages and different materials used for the manufacture of plugs.
Applicability
Bearings 713691010 are used in the front wheel hubs of passenger cars VAZ 2101-2109 (2112, 2121). Installed in wheels M-2141 produced by AZLK and ZAZ-1102 (1102).
If necessary, they can also be installed in the hub units of modern VAZ models instead of a roller bearing.
