Product Description
China golden supplier low cost brick making machine | dirt brick making machine | soil brick making machine
1. Brief introduction of soil brick making machine :
1. Compact structure soil brick making machine
2.Reliable performance soil brick making machine
3.Good service
4.Low power and good design soil brick making machine
5 Save manpower, and heat treatment for shaft, reamer main body etc;
6Hard surface reducer gear soil brick making machine
7 Easy maintenance soil brick making machine
This machine is used to produce solid bricks and hollow bricks with great quantities of holes and large section in all size of holes style .It is also suitable for all kinds of materials. Its features are novel structure, advanced technology, high extrusive pressure, high production and high vacuum degree. It adopts pneumatic clutch to control. Sensitiveness, convenient, reliable!
Model | TZJB30 |
Production capacity (pieces/h) | 12, 000~16, 000 pieces (standard brick) |
Extrusion pressure (Mpa) | ≥ 3.0 |
Vacuum pressure | ≥ 0.092 |
Shaping moisture content (wet basis %) | Shaping moisture content (wet basis %) |
Raw material plasticity index | 7 ~ 15 |
Required V-belt | 8V |
Required vacuum pump (water circulation type) | 2SK ~ 6 |
Power (kW) | 30 |
Overall dimension mm length × width × height | 3600*1200*1100 |
2.Our soil brick making machine available raw materials
This series brick machine is suitable for materials such as clay, soil,shale, coal gangue, slag, silt, mountain mud, and so on. Different materials fired different bricks, especially the color of the final bricks.
3. Structure of soil brick making machine :
The brick making machinery's axles, gear and other important spare parts extend the service life which are made by carbon steel and alloy steel through modulation or quench's heat treatment procession.
The dialing mud plate's transfer and material level control are fixed with protecting device which improves the plant efficiency of breakdown maintenance. And it also makes sure that it can't easily damage the main spare parts during usage.
The reamer adopt the floating shaft structure which can eliminate and reduce the machine's shacking and rocking times because of curve in principal axle after long time usage.
The blade of the reamer adopt the wear-resistant metallic material coating technology which make its life is four times to seven times longer than the common reamer. The lead has the function of light pressure delivery and high pressure extrusion which make the machine save energy from fifteen percent to thirty percent.
The reducer gear adopt hard tooth surface, good tenacity and wearability to make sure machine can serve you for long time.
Any questions and enquiry are warmly welcome !
