Export to UAE commercial robot brushless motor AVT-W9 wheeled robot chassis unmanned delivery vehicle with advantage in speed

Product Description

1. Product Introduction:

The 4wd robot platform kit adopts the BMS battery management system, which can effectively guarantee the long-term operation of the robot chassis. The chassis of this robot has a low chassis height, and the body has very good stability and can climb up to 30°. Compared with the crawler robot chassis, the wheeled robot chassis has the biggest advantage in terms of speed. The maximum traveling speed of the AVT-W9 wheeled robot platform can reach 16Km/H.

2. Product Application:

1. Exploration of inspection

2. The rescue vehicle

3. Scientific research and education

4. Fire control security guard

5. Special photography

6. Special transport

3. Product Feature:

1. Low height from the ground, stable transportation.

2. 16km/hour high speed, excellent transportation speed.

4. Product Specification:

Item	Data	Item	Data
Body Material	Alloy steel plate/Aluminum alloy	Dimension	908708310mm
Tire Diameter	310mm	Platform Dimension	695*384mm
Self Weight	56KG	Max. Load	50KG
Motor	48V DC Brushless Motor	Terrain Clearance	98mm
Protection Grade	IP64	Wheel Base	595mm
Steering Mode	Differential steering	Rated Torque	40NM
Ditch Passing Ability	250mm	Over-obstacle capacity	150mm
Reduction Ratio	10:1	Climbing Ability	30 Degree
Surface Treatment	Yellow coating	Running Speed	16KM/H
