Product Description
Touch Screen Automatic Turret Digital Display Micro Vickers Hardness Tester HVS-1000ZT
Product Description
Application and scope：
HVS-1000ZT Touch screen automatic turret digital display microvickers hardness tester It is mainly used for the measurement of the micro Vickers hardness of various metals and some non-metal materials. It can test various parts (machined parts, forgings, cast iron, steel castings, etc.), non-ferrous metals, thermal after-treatment parts, and various micro And thin parts, glass, ceramics, agate, gemstones, etc. for hardness measurement, at the same time suitable for carbonization, quenching and hardening layer effective depth, coating, surface coating and welding parts heat-affected part measurement. It can also be used to observe the internal metallographic structure of various metal parts and to collect, display and output the image.
Specification
Model | HVS-1000ZT |
Test force | 10gf (0.098N)、25gf (0.245N)、50gf (0.49N)、100gf (0.98N)、 200gf (1.96N)、300gf (2.94N)、500gf(4.9N)、1kgf (9.8N) |
Min.test unit | 0.025µm Electronic measuring eyepiece |
Exchange Scales | HRA、HRB、HRC、HRD、HRF、HV、HK、HBW、HR15N、HR30N、HR45N、HR15T、HR30T、HR45T |
Measuring range | 5~3000HV |
Test force application method | Automatic (loading, loading and unloading) |
Test microscope magnification | 100X (Observation) 400X(test) |
Test power and load retention time | 1~60s |
X-Y Test table | Size：100*100mm Maximum movement：25*25mm |
Data output | LCD display readout, built-in printer and RS-232 interface |
Max Height of Specimen | 110mm |
Distance from the center of the head to the outer wall | 110mm |
power supply | AC220V+5%，50-60Hz |
Dimensions | 320*500*570mm |
Weight | About 40Kg |
