RDJ Series Electronic High Temperature Permanent Creep Tester High Temperature Furnace Tensile Testing Machine
Negotiable
MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Business Type:
Trading Company
Year Established:
2016
Annual Export Value:
US$2.5 Million - US$5 Million
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Creep Tensile Testing Machine Creep Test InstrumentNegotiableMOQ: 1 -
High Low Temperature Universal Testing MachineNegotiableMOQ: 1
-
High Temperature Tensile Tester Price Testing MachineNegotiableMOQ: 1
-
Temperature Cycling Chambers\thumidity Tensile TesterNegotiableMOQ: 1
-
Automatic Relaxation And Creep Stress Rupture Testing MachinesNegotiableMOQ: 1
RDJ Series Electronic High Temperature Permanent Creep Tester High Temperature Furnace Tensile Testing Machine
Product Description
This creep test machine is applicable to the field of quality measurement, aerospace, iron and steel metallurgy, machinery
manufacturing, electronic appliances, automobile production, civilian nuclear energy, civil aviation, universities, research
institutes, commodity inspection, arbitration and other industries.
Test Standard:
* JB/T9373-1999 tensile creep test machine technology specifications
* JJG276 high temperature creep and durable test machine
* HB5151-1996 metal high temperature tensile creep test method
* HB5150-1996 metal high temperature tensile durable test method
* ASTM E139 Standard test methods for conducting creep, creep-rupture and stressrupture test
* ISO 204 Metallic materials uniaxial creep testing in tension.
* ISO/R 206 Creep stress rupture testing of steel at elevated temperature.
* JB/T9373-1999 tensile creep test machine technology specifications
* JJG276 high temperature creep and durable test machine
* HB5151-1996 metal high temperature tensile creep test method
* HB5150-1996 metal high temperature tensile durable test method
* ASTM E139 Standard test methods for conducting creep, creep-rupture and stressrupture test
* ISO 204 Metallic materials uniaxial creep testing in tension.
* ISO/R 206 Creep stress rupture testing of steel at elevated temperature.
Specification
Model |
RDJ-10/20 |
RDJ-50 |
RDJ-100 |
RDJ-200 |
RDJ-300 |
||||||||
Max. Load force(kN) |
10/20 |
50 |
100 |
200 |
300 |
||||||||
Accuracy |
≤0.5％ ; 0.5 class |
||||||||||||
Deformation accuracy |
<±0.5% of reading |
||||||||||||
Loading Speed |
0.05～50mm/min |
||||||||||||
Voltage |
220V/380V±10%；50Hz |
||||||||||||
Furnace |
||||||
Operating temperature range |
300℃～1100℃ |
|||||
Effective Length constant length |
150mm |
|||||
Furnace inner dimensions |
Ф90*380mm |
|||||
Furnace out dimensions |
Ф320*460(Can be adjusted according to user needs) |
|||||
Temperature control meter |
Yudian Temperature control meter |
|||||
Electric conduction Temperature control meter (optional) |
||||||
Thermocouple |
K type Even thermocouple |
|||||
S type Even thermocouple (optional) |
||||||
High-temperature furnace temperature accuracy (℃) |
Test temperature |
temperature fluctuation |
temperature gradient |
|||
300～600 |
±5 |
3 |
||||
＞600～900 |
±4 |
4 |
||||
＞900～1100 |
±3 |
5 |
||||
